Product Specifications
| Prod Model: |
RY-320/480E-5C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 2100*1100*2500(Mm): |
320 |
| Type: |
Ink Jet |
| Plate: |
Relief Printing |
| Embossing Structure: |
Rotary Letterpress |
| Color & Page: |
Multi-Colour Printing Press |
Product Description
Characteristics:
1. Adopt the anilox roller to spread ink.
2. Unwinding and rewinding are controlled by magnetism power brake, clutch. (or by automatic tension controller of Mitsubishi, made in Japan).
3. Printing unit adopt 360ºFor registration.
4. Printing unit have one infrared to dry the device group each.
5. The rubber roller can break away from automatically while parking, and running at a low speed, in order to avoid water being black to be dry.
6. The main motor is adopted the import step-less regulation of frequency conversion.
7. Unwinding, printing, varnishing, IR drying, laminating and rewinding can be finished in one process, this kind of printing machine is best for each printing companies to print on adhesive-paper labels and other commercial label.
| Main technical parameter: |
|
|
| Model | RY-320E-5C | RY-480E-5C |
| Printing speed | 60m/min | 60m/min |
| Printing color | 5colors | 5colors |
| Max. Web width | 320mm | 480mm |
| Max. Printing width | 310mm | 450mm |
| Max. Unwinding diameter | 600mm | 800mm |
| Max. Rewinding diameter | 550mm | 750mm |
| Printing girth | 175-320mm | 175-580mm |
| Precision of registration | ±0.10mm | ±0.10mm |
| Dimensions | 2100*1100*2500(mm) | 2300*1260*2700(mm) |
| Machine weight | About 2400kg | About 2600kg |
Ruian Zhenbang Printing Machinery Co., Ltd. is located at the leading industrial town in south Zhejiang, which has a long history of specializing in manufacturing series of trademark printing machine. Since its founding, the company has been holding on the creed of quality first and seek excellence, paying attention to inner management, after sales services, science and technical progress and information developing. It holds on the policy of uniting traders to occupy the market and take part in the competition. And thus achieved the rapid development of the enterprise.
Facing the drastic competition in the market, the companies makes its policy carefully and keeps its promise of quality basic and emphasize on quality, keep creditable as purpose, the company tries to improve its management system and perfects its sales network it answers back the society by its high quality products and effective services, and at the same time if believes that only by virtue of the strict standard on the product quality can the investing benefits of the clients be ensured more effectively.
Zhenbang enterprise hopes to cooperate with friends home and broad and progress together.
