Product Specifications
| Prod Model: |
SK-AU014 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Exposed Type |
| Material: |
Brass |
| Sensor: |
With Sensor |
| Spud Location: |
Back Spud |
| Water Consumption: |
Water Saving Type |
| Mounting Type: |
Wall-mounted |
| Drainage: |
Washdown |
Product Description
Specifications
1. Sensor operated
2. DC power supply
3. Laser mark logo acceptable
4. Water saving
5. Low power consumption
Automatic flusher Advantages
1) Conserves water
2) No unpleasant odors
3) Hygienic, no-touch activation
4) Easy installation
5) Built-in filter
6) Waterproof components
Our Advantages
1. Low power consumption (Operation Consumption is <60uA and Overall Power Consumption is <0.5W. 6V alkaline batteries can be used for 1-1.5years).
2. Saving water. The urinal flusher conducts TWICE flushing mode. When a person stands in the sensing area(before usage), the urinal flusher will auto flush for 2s; 2s after the person leaves, the urinal flusher will automatically flush for 7s. However, the urinal flusher only flushes ONCE if used continuously over 2 times within 1m.
3. The urinal flusher will automatically flush ONCE if no usage within 24hours.
4. Easy maintenance— There is a filter net in the installation, which is easy to adjust water flow and for cleaning.
5. Installation features— The embedded box with ultrathin design is installed into the wall, especially welcomed if the wall thickness is only 6CM.
6. Sensing range and flush duration can be adjusted by remote controller.
|
Style |
Exposed Type,
All-in-one design with adjustable flow rate valve at the inlet. |
|
Color |
Silver |
|
Components |
Embedded box, sensor, solenoid, batteries/converter, accessories |
|
Sensing Distance |
80cm (adjustable) |
|
Product size: |
L125*W86*H66mm |
|
Inner Packing Size: |
210×145×85mm |
|
CTN SIZE: |
446×315×650mm |
|
Package |
12pcs/carton, 19.5KGS/CTN |
|
Voltage |
100-240VAC 50/60Hz or 6V (2CR5) |
|
Water Temperature |
0.1-60 degree |
|
Environment Temperature |
0.1-45 degree |
|
Water Pressure |
0.05-0.7Mpa |
|
Operation Consumption |
<60uA |
|
Overall Power Consumption |
<0.5W |
|
Life cycle |
500,000 flush times |
|
Advantage |
Adjustable sensing distance&flushing duration by remote controller |
|
Usage |
Installed in families, offices, stations, hotels, hospitals etc. |
|
Suitable Installation |
New structure or Retrofit public urinals |
|
Finish |
Polished |
