Product Specifications
| Prod Model: |
EM-130-3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Measuring Range: |
1-160ml |
| Measuring Device: |
Liquid and Paste Filler |
| Packaging Capacity: |
70ppm Max |
| Air Consumption: |
100nl/Min |
| Function: |
3-Side Seal, 4-Side Seal |
| Automatic Grade: |
Automatic |
| Applicable Industry: |
Medical |
| Application: |
Dairy Products |
| Driven Type: |
Electric |
| Material Type: |
Liquid |
| Packaging Material: |
Plastic |
| Packaging Type: |
Bags |
Product Description
Automatic horizontal form fill seal machine for beverage
Product description:
The form fill seal packaging machine can be used to pack powder product such as milk powder, detergent powder, coffee powder, pesticide, and also can pack liquid, thick liquid and granule, etc. With corresponding measuring and filling device. The filling speed can up to 70 pcs/min max.
The form fill seal packaging machine can automatically finish bag forming, filling, easy tear notch making, print date, finished bag discharged. Reclosable zipper, spout, nitrogen flushing, unique bag shape, hole and round corner punching are optional.
Characteristics:
1) PLC control, English and man-machine interface, operating easy and simple maintain.
2) Advanced photoelectric sensor tracking system and servo motor pull for precise bag width and position of film.
3) Versatile machine could make doypack bag with zipper or spout, unique bag shape could be designed according to requirement.
4) Independent digital temperature controller for vertical and horizontal sealing, intuitive and accurate.
5) Easy and fast adjustment of change over, the machine has strength extensibility, could fill two or even more products into one bag by adding filling device
6) Smooth performance and low noise, perfect package appearance, sensible safety device and no pollution during production to get friendly working environment.
Main Technical parameters as following excel file
| Model | EM-130 |
| Filling volume | 1-160g |
| Measuring device | Liquid and paste filler |
| Pouch size | (65-140)mm * (75-180)mm |
| Packing speed | 70ppm Max |
| Power | 3.5kw |
| Pressure | 0.6MPA |
| Air consumption | 100NL/min |
| Dimension | 2850*920*1460mm |
| Weight | 800kgs |
| Function | 3-side seal bags, 4-side seal bags |
