Automatic Instant Paper Bowl Cup Making Forming Machinery
Product Specifications
| Prod Model: |
GX-H-2W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
50 Sets Per Month |
| Process: |
Paper Machine |
| Usage: |
Paper Cup Forming Machine |
| Type: |
Forming |
| Automatic Grade: |
Automatic |
| Computerized: |
Yes |
| Production Speed: |
35-45pcs/min |
| Voltage: |
380V 50Hz |
| Certification: |
CE, ISO |
Product Description
Automatic instant paper bowl cup making forming machinery
Automatic Paper Bowl Formimg Machine is an idea equipment of producing soup bowl, bigger size paper bowl, such as soup bowl, fast noodle bowl, large food cone-shaping containers and other fields etc
Brief Introduce:
GX-H12 type single PE coated paper cup machine is the automatic environmental machine with multi-running positions.
This machine runs a whole procedure of paper-feeding, cup-fan-wall sealing, oiling, bottom punching, heating, rolling, rimming, rounding and tripping.
It is an idea equipment of producing drinking cup, ice-cream cup and other food cone-shaping containers. This type paper cup machine is mainly used to make one side PE coated paper cups from 3 oz to 18 oz.
| Model | GX-H/2W-9 | GX-H/2W-12 | GX-H/2W-18(Special model) | GX-H/2W-32(Special model) |
| Production capacity | 45-55PCS/min | 40-50PCS/min | 35-45PCS/min | 30-40PCS/min |
| Required paper | 150-400gsm Single Side PE Paper or Double Sides PE Paper | 150-400gsm Single Side PE Paper or Double Sides PE Paper | 150-400gsm Single Side PE Paper or Double Sides PE Paper | 150-400gsm Single Side PE Paper or Double Sides PE Paper |
| Cup' s Range | (A) 50 -80MM, (B)35-90MM
(C) 35-55MM, (D)4 -10 MM | (A) 50 -90MM, (B)35-115MM
(C) 35-70MM, (D)5 -10 MM | (A) 60 -128MM, (B)80 -140MM
(C) 50 -75MM, (D)5 -10 MM | (A) 60 -128MM, (B)80 -180MM
(C) 50 -75MM, (D)5 -10 MM |
| Total power | 220/380V 50/60HZ 4.5KW |
| Air supply requirement | Working pressure: 0.4-0.6working
gas volume: 0.5m3 /per minute |
| Weight | 1400kg | 1500 kg | 1700kg | 1850kg |
| Overall dimensions (L*W*H) |
2500*1300* 1700mm | 2650*1300* 1700mm | 2850*1300* 1900mm |
3000*1400* 2000mm
|
Remarks:
I.Delivery time: 15 days after receiving clients' prepayment.
II.Payment term: 50% as prepayment by T/T, the balance of 50% should be paid before seller send the machine.
III. Valid time: This quotation is valid for one month.
IV .Quality Guarantee Terms:
Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.
V. Contact details:
Contact:Miss Susan
TEL:0086-371-55960109
HP:0086-15838007835
Address:No 99th,guoji road,jinshui zone,zhengzhou city.
