Automatic Labeling Machine for Flat& Round Bottles
Product Specifications
| Prod Model: |
GH-TB-1008 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Factory: |
Yes |
| Special Requirement: |
Can Be Cusotmized |
| Automatic Grade: |
Automatic |
| Application: |
Dairy Products |
| Type: |
Automatic Labeling Machine |
| Driven Type: |
Electric |
| Packaging Material: |
Film |
| Packaging Type: |
Cartons |
Product Description
Guangzhou Guanhao Offers
Automatic labeling machine For Flat& Round bottles for different kinds of products in all kinds of Industry.The Automatic labeling machine For Flat& Round bottles is suitable for
label the single-side of round bottle, single-side, dual-side and tri-side of square bottle; single-side and dual side of flat bottle (the bottles of shampoo, emulsion of bath, cooking oil, lubricating oil,
detergent and eyedrop etc.) in the industry of foodstuff, medicine, cosmetic and so on.
This machine the function is advance, easy operation, structure compact. Adopt to photoelectric examine, PLC control, Touch screen software operation, conveyor belt, nip bottle belt are all stepless for speed
adjust, label nicety; at the same time it has the function of no object no labeling, no label can revise by itself,
and automatic to check. This machine can used label alone, and also can used with other packing
machinery for automatic produce on line.
Application( Automatic labeling machine For Flat& Round bottles):
The Automatic Double Side labeling Machine is suitable for label the single-side of round bottle, single-side, dual-side and tri-side of square bottle; single-side and dual-side of flat bottle (the bottles of shampoo, emulsion of bath, cooking oil, lubricating oil, detergent and eye-drop etc.) in the industry of foodstuff, medicine, cosmetic and etc.Technical parameter: 1.Applicable scope of product: according to customer sample 2.Applicable scope of label: according to customer sample(non transparent label); 3.Production capacity:50-100bottle/min; 4.labeling accuracy:±1.5mm(arc surface), ±1mm(flat surface)5.voltage:220V/50HZ single phase;6.power: about 2KW;7.conveyor:82mm width POM chain plate,speed0-15m/min,distance to the floor 750mm±25mm;8. program control: PLC and touch screen man machine interface 9.Applicable scope of paper roll:inner diameter 76mm,external diameter maximum 300mm. Main configuration:1,Machine body: 304# stainless steel2,Machine leg: 201# stainless steel3,Guardrail: 304# stainless steel4,Program control: German Siemens5,Machine-interface: German 7' inch touch screen.6,Photographic inductive sensor: German Leuze7,Relay and air switch: France Schneider8,Motor transfer inductive : USA AB9,Conveyor material: 152mm width POM chain belt piece.10,Conveyor motor: 370W Taizhou ziguang AC motor11,labeling motor: 400W France Schneider servo motor12,Bottle separate motor: 25W domestic AC motor13,Cramping motor: domestic brand14,Labeling press belt motor: 90W AC motor15,Label collecting motor: domestic brand16,right and left scrolling wheel:high elasticity sponginess wheel17,belt pressing material:imported synchronous belt;18,right and left bottle clip belt:(POM) double layer chain type conveyor 19,Exposure: stainless steel,Anodize oxidation treated alloy,electroplate 45# steel,plastic 1.Conveyor 2.Bottle separate wheel 3.clamping positioning unit 4.left labeling unit 5.right labeling unit 6.touch screen 7.press label unit 8.reel label unit 9.conveyor unit 10.electronic unit (1)conveyor:Use for delivery waiting labeling product or finished labeling product. POM chain belt piece was driven by motor (2)Labeling unit:It driven whole roll of label and reel label into every piece then support to product. It consists of servo motor, label separate, send label disc, guide label axis, brake unit, detect label unit, reel label unit, synchronization label collection unit, elevator, front and back adjustment unit.(3)Guide right device:Staff placed bottle on conveyor and the guide right device will separate bottle into distance, keep the bottle moving direction as same as the conveyor. In a hand, it consist by bottle separate wheel and clamping positioning unit .(4)Press bottle unit: Press and tight bottle on conveyor, in addition conveyor moving speed tight the bottle and send it to labeling position & label collection position.(5)Touch screen: It used for controlling automatic running programmer, set single parameter on it, in the same hand, it not only setting, saving, reading all kind of labeling parameter.(6)volume label:Brush label on product surface. It compose of Sponge and adjustment unit.(7)Electronic box:Component control such as servo motor driven, steady power supply, motor transfer inductive , PLC and so on .Technical Characters:
1. The PLC control combined with touch screen providing user friendly operation and high precision.
2. The memory of 60 groups of labeling specifications can exchange the production line quickly.
3. The equipment is up to the mustard of GMP requirements and made of SS304 which is treated by anodic of high-class aluminum alloy.
4. The machine has many functions such as count, attach label and so on.
5. The labeling position of height and angle can be adjusted.
6. The modular-design makes this machine suitable for operation together with other machines or in a production line.
7. The transparent label sensor is optional.
Technical Specification( Automatic labeling machine For Flat& Round bottles): | Voltage | 220V 50Hz Or 110V 60Hz |
| Power (KW) | 2.2 |
| Labeling speed | 100-350 |
| Scope of container | L:15-150 W:10-100 H:40-350 |
| Scope of label | L10-200 H:15-180 |
| Labeling accuracy | ±1 |
| Max reel diameter | 420 |
| G.W (KG) | 250 |
| Shipping Diameter | 2800*1450*1360 |
|
|
Guanhao stepped into Packing machinery business in 1994 with the far infrared ray heating shrinking machine form only. Within a small period of time Guanhao also introduced other types of Shrinking i. e. Automatic sleeving and sealing, cutting machine and Sleeving label shrinking machine in 2000, and Filling machine in 2003. Gradually formly Accessories processing, produce, assemble, polished, a complete production, Although; Guanhao extended its scope of products through launching various forms of Filling machine and labeling machine in its product range; However it achieved landmark milestone when it started producing the Car Oil Sprayer, lubricating oil Spraye, Antirust Sprayer labeling machine in 2005. This has been a matter of pride for Guanhao to achieve this milestone and became the first among its competitors to produce Filling machine, labeling machine, capping machine, shrinking machine in Guangzhou, China.
At the moment Guangzhou stands as 3th largest Packaging machinery company with the strength of more than 150 employees at its end. This storming achievement on the part of Guanzhou is unequivocal testimony of enthusiasm, competence and consistency as core principles of its functioning. Today we are a reliable name in the Packing machinery world; Winning bulk of the market share by dint of our consistent hard work and dedication to our principles. However despite this meteoric rise we still consider our Stuff and honor clients as first step and are ready to take up future challenges with the same spirit and zeal; Promising to regard the trust of our valued customers as our most sacred asset.
