XBG-60C Automatic lunch box fill and seal packing device
Features:
1.For lunch-box
2.Stainless steel body
3.CE Certification
4.Can be customized
5.With date coding optional
Applications:
Suitable for packing milk, soymilk, soy paste, bubble black tea, juice, honey, ketchup, mineral water and so on.
Description:
XBG series Linear Type Cup Fill & Seal and Code Machine is new type multifunctional machine that combine cup filling, sealing and coding.
The machine has below functions: Falling cup, dust sucking, solid filling, liquid fillling, coding, vacuum, Nitrogen gas filling, sealing, photocell rectifying, cutting, waste film collection.
Functions can be added or removed according to their need. It installs PLC system, safety protection device and breakdown alarm indication device which can guarantee high productivity and process stability.
It adopts the new technologies: Sealing of automatic positioning, independent sealing head.
Specifications:
This machine is our new product and very suit for using in box-shape container.
And it is mainly desinged for sealing lunch box. We can produce the Aluminum mould according to your sample. The feeding boxes should be done by manual. The sealing is very beautiful and stability.
The machine can be added coding device.
Main technical parameters:
Model: | XBG60C | XBG60C-2 |
Packing speed: | 500-800pcs/h | 1300-1700pcs/h |
Motor Power: | 370W | 750W |
Total power: | 3KW | 5.5KW |
Source: | AC 220V/50HZ | AC 380V/50HZ |
Weight: | 500KG | 700KG |
Dimension(L*W*H): | 2500*670*1500mm | 3200*870*1500mm |
Air source: | 0.65-0.85Mpa | 0.65-0.85Mpa |
Air consumption: | 0.4m³/s | 0.6m³/s |
