Model: VFFS-350L
Use
This machine is suitable for packing food, chemical, pharmaceutical, condiments, daily necessities
And other liquid materials. Such as ketchup sachets, miso soup, sauce, oil, beverage, yogurt,
Shampoo, hand sanitizer.
Character
1. It can full automatic carry out the process of sachet-forming, material-filling, sides-sealing,
Sachet-cutting and quantity-counting.
2. Date and batch number printing device can be added and conveyer belt.
3. Packaging products can select by tooth type cutting, scissors type flat cutting or with a "straight-line" notch cutting. With easy tearing mouth device, for customers to open the packaging
Bag conveniently.
4. The pump body is made of all stainless steel, environmental clean.
5. Volume measurement, large range of weight adjustment, accurate measurement.
6. Stepping motor with photoelectric switch positioning, conveniently adjust length without stopping the
Machine working, high precision bag forming.
7. It can easily adjust the products packing weight, temperature, packing speed.
8. Intelligent cursor positioning 1-2 bag can be fixed in place.
9. Seal with intelligent temperature control table, the sealing error control within 2 degrees.
10. A computer controller is the first domestic patent products, the use of advanced CPU chip,
Imported power switch. All the features are used in key operation, digital display.
11. Numerical control cutter, can set 2-99 bags(bags connected) automatic counting and then cutting.
12. When the roll film is end, machine will stop running automatically. It can automatic detect the fault.
Technical parameter
Roll of film's width
Max 350mm
Bag length width
L: 50-280mm W: 60-175mm
Packing material
PET/AL Plating/PE, PET/PP, BOPP Film, Nylon
Compound film and other materials can be heat sealed
Bag type
3 side sealing, Back seal
(choose one)
Measurement range
100-500ml
Packing capacity
30-60 PCS/min
Outer size(L x W x H)
1000X950X2000mm
Total power
2.3kw
Machine weigh
400kg
After sale service:
1. Transport Service:
As we on the agency for machines transporting, we provide buyers safety and timely shipping from start to end. Any updates will inform to buyers.
2. Installation, Commission and technical guidance:
Before shipment, machines will be tested by our technicians to make sure they can work well.
Free for customers operating personnel training, to ensure that the customer's skilled operators can operate equipment before leaving the factory.
3. Product quality standard and quality promise:
Our machine and its relevant parts meet the relevant national standards or industry standards, we have responsible for 1 year guarantee. We will give solution to buyers within 1 day when getting feedback if anything happen.
4. Parts supply service:
We responsible for supplying reliable quality parts to buyers for free when machine leaving the factory. If after receiving machine and still need more parts, we can supply them with reliable and reasonable price in order to ensure continuous production line.
5. Technical upgrades:
When have new technology coming, we will keep buyers informed and thoughtful to provide buyers with better maintain and machines.
100-500ml liquid sachet form fill seal machine
