Product Specifications
| Prod Model: |
T1650F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tt Diameter: |
1650mm |
| Automatic Grade: |
Semi-Automatic |
| Driven Type: |
Electric |
| Type: |
Prestretching Wrapping Machine |
| Packaging Type: |
Cartons |
| Applicable Industry: |
Apparel |
| Application: |
Dairy Products |
Product Description
17 years experience in designing, testing and producing packing machine
Successfully establish good partnership with COCA COLA, PENSI, Panasonic, Canon. Key Words: Strech wrapping machine, pallet wrapper, semi-auto stretch wrapper, pallet wrapping machine, stretch pallet wrapper, stretch wrapping equipment, packing machine, package machine
Technology dataMax load size(mm) 1200(L)X1200(W)X2400(H)
Turntable diameter 1650mm
Turntable height 77mm
Turntable weight capacity 2000kgs
Turntable speed 3-12rpm
Machine weight 500kgs
Electrics 220V 50Hz 1Phase
Power 1.2kw
Machine dimensions (mm) 2625(L)X1650(W)X2895(H)
Packing efficiency 20-40load/h base on loadController: Omron PLC
Operator interface: Independent buttons
Pre-stretch level: 250% (optional 100% to 300%)
Load height sensor: Photoeye sensor
Wrap counters: Independent top and bottom THE MACHINE MEETS CE STANDARDS COMPLETELY
We are the Expert for Packing
We can help you in packing line.
Any questions please feel free to let me know -
|
Control system |
PLC control system |
|
Photo eye pallet height sensor |
|
3-12 RPM variable turntable speed by frequency changer |
|
Turntable |
Go home position after wrap cycle finished |
|
Soft start/soft stop |
|
Heavy duty chain drive |
|
Film carriage |
Powered pre-stretch system to 300% to min film consumption |
|
Film delivery barlable speed by spparate AC Drive Motor |
|
Heavy duty double-chain carriage lift, calm and safety |
|
Technology Data |
Max load size(mm): 1200(L)X1200(W)X2400(H) |
|
Turntable dia: 1650mm |
|
Turntable Height: 77mm |
|
Turntable weight capacity: 2000kgs |
|
Turntable speed: 3-12rpm |
|
Electrics: 220V 50HZ 1 phase |
|
Power: 1.5KW |
|
|
Packing efficiency: 20-40 load/h base on load |
|
Option |
Ramp |
|
Top plate |
