Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
SUS304 |
Product Description
Brief introduction
QGF series mineral water filling machine is a self-developed new product by our R&D department to meet the requirement of multi-usage demands for our customers. The machine is based on the introduction of foreign technology, combined with our years of manufacturing experience. The machine combines Washing, filling and capping, with scientific and rational design, beautiful shape. It allows the machine to fill different type of the bottles. It is normally used as mineral water filling machine. However, it can also be used for fill PET bottle with fruit juice and tea at high temperature by simply change the valve. It can be connected with our others machines to form the mineral water filling production line. It is easy in maintenance, with automation
1. Rinsing empty bottle, filling, and capping functions are integrated in one system, fully automatic synchronized working.
2. Bottle travels on neck to neck from in-feed till out-feed resulting scratch free movement of bottle.
3. Pressure filling nozzles deliver fast, efficient, and accurate dispensing with minimal dripping and leakage.
4. No Bottle No Filling, no caps no capping, no caps auto stops.
5. When bottle jam auto stop, machine accident auto stop.
6. Open the window when machine running, machine auto paused.
7. Heavy duty stainless steel filling pump & rinsing pump.
8. Food grade 316L or 304stainless steel contact parts, smooth & fine polish, no dead angles.
9. Adopted first class component from Mitsubishi, OMRON, SIEMEN, With PLC, invertors control, touch screen, sensor, switch and other electric parts.
10. Machine and cable arrangement designed according to CE standard and all safety standard.
|
Model |
18-18-6 |
|
Heads of rising, filling, capping |
|
Capacity BPH |
3000-6000B/H
on basis of 500ml bottle |
|
Suitable bottle diameter |
Diameter 50-110 mm, Height :170-310mm
for bottle 330-2000ml |
|
Main TOTAL POWER |
3.0KW |
|
Weight(KG) |
1800 |
JIANGMEN GREENFALL WATER TREATMENT TECHNOLOGY Co., Ltd Located in China's first overseas Chinese of JIANGMEN. Since 1996 the company since its establishment, our factory purpose is improve water quality, benefit of humanity, fervor-self, contributing to society.
Our factory manufacture complete water plant equipment. Include injection machine, blowing bottle machine, water treatment equipment, ozone system,
Filling machine, labeling machine, packing machine and palletizer etc.
As one of the leading manufacturers in drinking water treatment and bottled water engineering (covering water dispensers) in China, we are pursuing good reputation in the global market also. Our products are selling well in Canada, French, USA, Japan, Korean, Russia and Indonesia. And we have more customers from USA, Mexico, Ecuador, Australia, Singapore, Thailand and Brunei. We have a good beginning in most of African countries.
The main products of the company
1, 2000BPH---20000BPH hot liquid filling, middle temperature beverage production line
2, 2000BPH---36000BPH Mineral water and purify water production line
3, 2000BPH---20000BPH Gas beverage production line(PET, glass bottle)
4, 2000BPH---12000BPH Glass bottle wine complete production line
5, 2000BPH---20000BPH Pulp beverage mixed filling machine
6, 60BPH---1200BPH barrel mineral water, purify water production line
Plastic injection machine, Blowing bottle machine, Mould etc
Bottle unscrambler, Labeling machine, Shrink packaging machine, etc
Ozone system, ultraviolet sterilization system, air shower, laboratory equipment etc
Purified Water Treatment Equipment, Mineral Water Treatment Equipment, Seawater treatment Equipment, Brackish Water Treatment Equipment, etc.
Providing "Quality Products, Excellent Service, Competitive Prices and Prompt Delivery", we are now looking forward to even greater cooperation with overseas customers based on mutual benefits. If you are interested in our products, please feel free to contact us for more information.
