Product Specifications
| Prod Model: |
HJG-500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Maximum Width Of Machine: |
900mm |
| Work Method: |
Round Knife Cutting |
| Type: |
Roll Slitter |
| Classification: |
Slitting Rewinding Machine |
Product Description
PARAMETERS FOR THE SMALL THERMAL PAPER SLITTING REWINDING MACHINE IN CHINA
Material: 45-200g paper, thermal paper, cash register, ATM roll etc
The maximum width of the jumbo reel: 500mm
The width of the small slitted reel by the machine: 20-500mm
Working speed: 160m/min
Slitting speed: 5-160m/min
The maximum unwinding diameter: 1200mm
The unwinding shaft: locked 3" air expanding shaft
Unwinding tension force 10N
The maximum rewinding diameter: 200mm
The rewinding shaft: the locked 3" air expanding shaft
The main motor: 2.2 KW frequence inverter control
The fan motor: 0.55 kw single phase motor
The transimmission way: chain, gear and synchronization strap.
Slit: round cutter(the size is according to the machine)
Shaft: 80 hard aluminium alloy
Length of guide rod: 520mm
Working voltage: three phase four line, 380V, 50HZ
Total power: 4.5 kw
Weight: about 1600 kgs
FEATURES FOR THERMAL PAPER CUTTING MACHINE
--there are automatic loading/unloading function on the unwinding stand part
--automatic tension force controller.(20N)
--web guide adopt EPC control(air expanding shaft 3 inch 76mm)
--the paper inserting part is controlled by PLC with pneumatic,
--all of the operation is controlled by PLC
---machine starting: only press the POWER button, all of them are completed by PLC.
Ruian Huida Machinery Manufacturer Company Ltd. We registered in 2003 year but we started to produce the automatic thermal paper slitting machine since 1995. Then we have cumulated more than 20 years experience to produce the machinery.
We mainly produce the thermal paper slitting machine, cash register paper roll slitting machine, FAX/ATM/POS paper roll slitting machine, fully automatic slitting rewinding machine, fully automatic roll to sheet cutting machine, automatic paper sheet cutting machine, paper tube machine, paper tube cutting machine, paper core machine etc
Besides, we also produce some machine parts, like blades, shafts, all kinds of springs etc
We know more about thermal paper rolls produce process. Besides we are one professional thermal paper slitting machine manufacturer, we also know the correspond thermal paper cores, thermal paper package etc.
Automatic roll to sheet cutting machine is our another main product. We can not only produce semi-automatic simple roll sheet cutting machine, but also we can produce the fully automatic rotary type roll sheet cutting machine with four or six jumbo rolls. It adopt the advanced technology to guarantee the roll sheet cutting machine's working stable.
About detail, please browse our website: HTTP: // www.dragon-machine.com
Another paper tube machine is one of our major products, we can produce different type paper tube machine and paper tube cutting machine.
For detail paper core machine, please view: HTTP: // www.paper-core-machine.com
Our factory located in Ruian City which has many printing machine manufacturer, plastic machine manufacturer, pharmaceutical machinery manufacturer etc. It is convenience to arrive our factory. There is Wenzhou Yongqiang airport near our city. Warmly welcome the customer from all over the world to visit our factory and see our thermal paper slitting machine and roll sheet cutting machine.
