Axial Flow Fan for Machine

Name: Axial Flow Fan for Machine
Brand: China-Manufacturer-Directory.com
SKU: 612670714
Availability: InStock
Rating: 4.8 (54 reviews)

Supplier:	Ruian Chuangbo Machinery Co., Ltd.
Price:	US $ 10-20/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	FZY-D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	150 and 200
Frequency:	50Hz
Phase:	2 Phase
Voltage:	220V
Type:	Axial Flow Fan
Power Supply:	Electric
Application:	Industrial
Remote Control:	Without Remote Control
Timer:	Without Timer
Power:	<100W
Installation:	Wall Mounted
Speed:	2600r/Min
Material:	Aluminum Alloy Shell, Plastic Blade

Product Description

Axial flow fan is consists of aluminum alloy shell, plastic blade and electrical machine. It has such advantages of small size, installation convenient, large wind, small vibration and low noise.

The scope of application:
It is mainly used in ground automatic control device, which needs big air flow, and ventilation and heat dispersion of large-scale electric equipment, cabinet and electric welder. It can also be applied for ventilation, breathing and purity in buliding and workshop.

Type	Voltage	power rating	phase number	input power	electric current	rotate speed
150FZY2-D	220V	50HZ	1	30W	0.15A	2600r/min
200FZY2-D	220V	50HZ	1	65W	0.30A	2600r/min
200FZY4-D	380V	50HZ	3	65W	0.18A	2600r/min
Type	Blastvolume	Noise	Weight	Electric power	Insulate	Environmental conditions
150FZY2-D	5.5m³ /min	65	0.9kg	1.0/400μ F/V	E	2
200FZY2-D	13m³ /min	70	1.5kg	1.0/400μ F/V	E	2
200FZY4-D	13m³ /min	70	1.5kg		E	2

Shape and Assembly Dimension
Size type	D	D1	D2	d	h	L
150FZY2-D	150	158	173± 0.15	4.5	4.5	58.5
200FZY2-D	200	210	235± 0.15	6.3	6.8	73.5
200FZY4-D	200	210	235± 0.15	6.3	6.8	73.5
Remarks: bidirectional fan

Ruian Chuangbo Machinery Co., Ltd. It was founded in 1995, and is located in the coastal city of southen Zhengjiang_Ruian.
Our company is specializing in producing printing machinery accessories:

Printing Rollers: Aluminum guide roller, chrome steel roller, aluminum reculate pattern roller, rubber roller;

Flatulence Axes: Slip-style inflatable axis, slab-style inflatable inflatable shaft, inflatable-strip key shaft;

Fans: Centrifugal fan, axial-flow fan;

Torque Motor: Torque motor controller, manual tension controller, electrical ink pump;

Other Printing Accessories: Magnetic powder clutch, magnetic powder brake, pneumatic diaphragm pump, pneumatic diaphragm pump, permanent magnent motor etc.

Our company has powerful technical strength, advanced technology, introducing foreign advanced production equipment and detection means. Our products have passed the China National Mandatory Certification(referred to CCC certification), which is issued by China Quality Certification Center.
