Supplier: | Huizhou Dayawan Fox Etech Limited |
---|---|
Price: | Negotiable/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,CIF,EXW |
![]() |
Prod Model: | FNS-B756L-L |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: | Silver Gray |
Type: | Wired |
Application: | SOHO |
Transfer Rate: | 10/100/1000Mbps |
Ports: | 6 |
Model NO. |
FNS-B756L-L |
CPU |
Support LGA1155 Intel Core™ i 3 /i5/i 7 32nm/22nm Processor |
Chipset |
Using Intel® B75 Express Chipset |
Memory |
Dual-channel SO DDR 3 1333/1066 memory slot , Max. up to 16 G B |
Display port |
1* DB15 VGA port |
Network Function |
Integrated 6 * Intel 82 583V 10/100/1000Mbps Ethernet |
Support ing Wake-on-LAN and PXE function |
|
Wireless Network |
Providing 1 * Mini-PCIE slot, support WIFI / 3G module |
Storage |
Providing a 3.5 / 2.5 inch SATA disk location |
1* MSATA slot, support SSD 6 Gbps |
|
1* CF card slot |
|
Panel Port |
1* COM ( CISCO Standard Interface ) |
2* USB 2.0 port |
|
6 * LAN port |
|
1* POWER Switch |
|
1* POWER_LED , HDD_LED Indicator |
|
1* VGA port (Rear panel) |
|
Cooling system |
1 * CPU FNA, 2 * SYSFAN |
Operating Temp. |
- 0 °C ~5 0°C |
Storage Temp. |
- 2 0°C ~ 7 0°C |
Humidity |
5% -95% (relative humidity; non-condensing) |
Anti vibration |
5 ~ 3 00Hz/random operating |
Power |
1U ATX Power supply , 220W or 275 W (optional ) |
Installation |
1 U chassis frame |
Material and Process |
Surface sandblasting oxidation process ( S ilver gray ) |
Size |
430mm (L) * 280mm( W) * 46.2mm( H) |
