Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Techniacl Specifications:
Items Specifications
Total operating weight 8260kg
Transportation dimension 7565× 2240× 2830mm
Wheel base Front Wheel Base 1930mm
Rear Wheel Base 1830mm
Tread 2020mm
Min Ground Clearance 400mm
Loading bucket capacity 0.9m3
Backhoe bucket capacity 0.3m3
Digging up capacity 50KN
Bucket discharge height 2200mm
Backhoe bucket height 3450mm
Max. Digging depth 4100mm
Bucket slewing(swing)angle 180°
Model 4105
Rated power 83KW, 2400r/m
Min fuel consumption 305g/kw. H
Max (peak) torque 337N. M
Displacement 5.05L
Max travel speed 30km/h
Axles Frontrear wheel reduction type
Front drive device type
Wheel Tire size 17.5/25
Wheel pressure 0.22Mpa
Steering angle ± 38°
Minmum turing radius 4025mm
System pressure 22Mpa
Flow 156L/min
Bucket life time 5s
Bucket lower time 2.5s
Bucket discharge time 1.2s
Hydraulic pilot controlling system Hydraulic Sensing Prior Controlling
CINA Interntional Trading (China) Co., Ltd is a company mainly deal in the crane sale, crane maintenance and crane renting field. At present, we mainly deal in China first class brand XCMG products, including, , truck crane, crawler crane and all-terrain crane. We provide garanteed products to our customers with professional services and reliable credit.
Ourself crawler crane QUY50 in project field.
