Product Specifications
| Prod Model: |
SJ1000-1400 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Eight Lines Heat-Sealing & Cold-Cutting Bag Making |
| Model: |
Sj1000-1400 |
| Max Bag Width: |
180*8mm |
| Max Bag Length: |
1000mm |
| Bag Thickness: |
0.009-0.1mm |
| Speed: |
20-120PCS/Min |
| Main Motor: |
1.5kw |
| Weight: |
1100kg |
| Dimension: |
6500*1700*2000mm |
| Machine Type: |
Bag Forming Machine |
| Type: |
Plastic Bag Making Machine |
| Bag Type: |
Shopping Bag |
| Computerized: |
Computerized |
| Bag Material: |
Plastic |
Product Description
Futures:
1. steel plate machine frame , starting stable.
2. PLC control, auto counting and set counting alarm
3. it is shaped one time from film roll to finished bag
4. when the system appear feeding and blocked bags, the computer will stopped by itself.
5. it is high efficiency, so save time and power.
6. it is controlled by inverter.
7. it use heat-sealing & cold-cutting equipment.
8,with servo motor to feeding
9. it is a ideal machine to produce non-printing bag , flat bag , t-shirt bag , etc.
| Model | SJ-1000 | SJ-1200 | SJ- 1 400 |
| Max bag width | 180 X8 mm | 230 X8 mm | 300 X8 mm |
| Max bag length | 1000 mm | 1000 mm | 1000 mm |
| Bag thickness | 0.009-0.1mm | 0.009-0.1mm | 0.009-0.1mm |
| speed | 20-1 2 0pcs/minX8 | 20-1 2 0pcs/minX8 | 20-1 2 00pcs/minX8 |
| M ain motor | 1.5KW | 2.2KW | 2.2KW |
| T otal power | 7.5KW | 8.5KW | 9.5KW |
| weight | 1100KG | 1300KG | 1600KG |
| O utline size | 650 0 X 1 7 00 X 2000 mm | 650 0 X 1 90 0 X 2000 MM | 65 00 X 21 00 X 2000 MM |
In the machine field, "Hongguang" has fast developed by study and apply advanced technique. "Hongguang" machinery has passed ISO9001: 2000 international quality system and own imports and exports right. According to the service concept of "cast elaborate, good faith manager". "Hongguang" Machinery provides lifelong maintenance for all the products that it sells.
At the same time, according to the different production conditions and capabilities of different customers, we provide convient, scientific and economic project budget plans. By means of outstanding technical support, and taking into consideration what our customers want, we lead them to the success that they desire. "Hongguang" Machinery's strength relies on management strategy that places service firstand foremost, and management operations that achieve excellent scientific results. We always endeavor to carry forward the spirit of the nation, creat a brand name for the nation.
At the start of the new century, we have put for ward new lines of products that include thansparent film 3D packer, film blowing machine, bag-making machine, and printing machineetc...Our products have seen excellent sales at China, as well as in 30 different regions and countries in Asia, Africa and Europe.
"Hongguang" Machinery are willing to cooperate with friends of various circles at home and abroad, March forward hand in hand and create brillingce again.
