Product Specifications
| Prod Model: |
B6000 |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
Product Description
Operation
Processor
MARVELL PXA270 CPU 520MHz
Operation
Microsoft Windows Embedded CE 5.0/CE 6.0
Memory system
ROM 64M Byte Nor Flash
RAM 128M/256M Byte Mobile SDRAM
TFLASH BOOTH Support 4G/8G/16G TFLASH card
Media
Screen
3.5 inches 320x 240 partly pass partly returns to technical, technical grade TFT, and touching screen function
Sound
Wolfson the multimedia chips, integrate the speaker and earphone connection, supports the sound recording and play backing
Keyboard
Entire numeric keyboard, 5 function feather keys, quick key and sound adjustment key and so on
Data communication
Standard layout
RS232, USB HOST & Device
Bluetooth 2.1, Class II Standard
802.11b/g
Choice disposition
GPRS/CDMA/3G /433 Passes on the communication module without the line number
Date
Gathering
GPS Module
May choose the built-in GPS module
Barcode Scan
Univariate with the PDF417 laser two Kinds or univariate and two-dimensional CMOS engine
RFID
@ Integrate
RFID, ISO 14443 A/B, ISO 15693
CMOS
3 million picture element automatic focusing color camera, and has the high luminance xenon flashing light
Electrical Specification
Battery
Main battery 3400mAH/3.7V polymer lithium battery, removable Battery backup Built-in 1000mAH/3.7V polymer lithium battery, is not removable
Adapter
Input AC100-240, ~0.5A, 50-60Hz output DC 5V± 10%, 2.0A
Physical Specification
Size
150mm(L)x76mm(W)x 30mm(H)
Weight
350g (include the battery)
Rk Environment
Temperature
Operation - 20 degrees Celsius to +70 degrees Celsius, Memory - 40 degrees Celsius to +70 degrees Celsius
Humidity
5%~95% RH Non-congealment condition
Protection
IP65, The complete protection and raises the dust from each direction flushing water, against vibration and hit
| Operation | Processor | MARVELL PXA270 CPU 520MHz |
| Operation | Microsoft Windows Embedded CE 5.0/CE 6.0 |
| Memory system | ROM 64M Byte Nor Flash
RAM 128M/256M Byte Mobile SDRAM
TFLASH BOOTH Support 4G/8G/16G TFLASH card |
| Media | Screen | 3.5 inches 320x 240 partly pass partly returns to technical, technical grade TFT, and touching screen function |
| Sound | Wolfson the multimedia chips, integrate the speaker and earphone connection, supports the sound recording and play backing |
| Keyboard | Entire numeric keyboard, 5 function feather keys, quick key and sound adjustment key and so on |
| Data communication | Standard layout | RS232,USB HOST & Device
Bluetooth 2.1,Class II Standard
802.11b/g |
| Choice disposition | GPRS/CDMA/3G /433 Passes on the communication module without the line number |
Date
Gathering | GPS Module | May choose the built-in GPS module |
| Barcode Scan | Univariate with the PDF417 laser two Kinds or univariate and two-dimensional CMOS engine |
| RFID | · Integrate RFID ,ISO 14443 A/B, ISO 15693 |
| CMOS | 3 million picture element automatic focusing color camera, and has the high luminance xenon flashing light |
| Electrical Specification | Battery | Main battery 3400mAH/3.7V polymer lithium battery, removable Battery backup Built-in 1000mAH/3.7V polymer lithium battery, is not removable |
| Adapter | Input AC100-240,~0.5A,50-60Hz output DC 5V±10%,2.0A |
| Physical Specification | Size | 150mm(L)x76mm(W)x 30mm(H) |
| Weight | 350g (include the battery) |
rk Environment
| Temperature | Operation - 20 degrees Celsius to +70 degrees Celsius, Memory - 40 degrees Celsius to +70 degrees Celsius |
| Humidity | 5%~95% RH Non-congealment condition |
| Protection | IP65,The complete protection and raises the dust from each direction flushing water, against vibration and hit |
