1. An overview
Electromagnetic flow meter is designed specifically for the water industry to meet the city's water supply to ensure the accurate calculation, the scene is widely used in places without power supply, such as urban water supply, sewage treatment, water conservancy and other industries.
Electromagnetic flow meter specially designed sensor excitation system, and high-performance lithium battery-powered systems, and uses 16-bit AMD embedded processor power, with all-digital signal processing, measurement stability, high measurement accuracy, anti - Interference ability, and other features, automatic bi-directional flow measurement, on-site instantaneous flow of positive and negative cumulative total to show that self-diagnosis alarm FAULT Far GSM wireless data functions, the user through the powerful GSM / GPRS remote management software system can flow Far total wireless data storage functions.
2. The main technical parameters
Diameter: DN10-DN1200 DN150- DN3000(Also optional plug-in battery-powered electromagnetic flow meter)
Pressure: 0.6~4.0Mpa(Special pressure customizable)
Precision: ± 0.5%\± 1.0%
Measuring range: 0 ~ 12m / s
Media Measurement (conductivity): > 20μs/cm
Medium temperature: -10 c ~ 100 c
Ambient temperature: -10 c ~ 60 c
Humidity environment: ≤ 95% (relative humidity)
Power supply: 3.6V/DC built-in lithium battery-powered, continuous working hours, more than 5 years
Electrode materials: 316L stainless steel, HC, HB, titanium, tantalum, platinum / iridium alloy
Lining materials: Poly chloroprene rubber, polyurethane rubber, PTFE, F46, PFA
Connections: Flange type, plug-in, clip -
Structure in the form of: A body divided body
Level of protection: IP68
Display: LCD large-screen liquid crystal display instantaneous flow of positive / reverse the cumulative total and prompt warning
Output: The output pulse 0.0001-10m / p pulse width can be set to 20ms (passive output optocoupler)
Means of communication: GSM wireless data transmission (packet in the form of text messages)
3. Appearance and size of the installation
Appearance and size of the installation (type flange connection) Figure 1, Table 1
4. Display
The instrument for large LCD screen LCD, two-line display, scheduled for the last 10 cumulative flow shows that the greatest value 9, 999, 999, 999 display can be displayed alternate is, the reverse flow of the cumulative value of the schedule for the next five instantaneous flow shows that the largest display 99999 value can be displayed alternate is, the reverse flow of transient value and prompt report to the police.
