Product Specifications
Product Description
Product Description
1) SGK series Auto Plastic Pipe Belling Machine with drawing device and program interface concerned is used with extruding machine.
2) Adpoting translation and electric heating type.
3) A transfer swith of expanding solvent type socket(Straight port ) and expanding seal loop typepiepe socket(R port) on its panel
4) All the key electric control elements are imported. The system characteristics are steady and reliable.
5) Certification: ISO9001: 2000
6) Delivery lead time: 40 days
Pipe diameter: 110-630mm
|
Electric system
|
Length: 4-6m
|
Compressed air pressure: 0.4-0.6Mpa
|
Hydraulic system
|
Water pressure: 0.2-0.3Mpa
|
Oil-pump power:3KW; speed:1430r/min;
|
PLC: FX-40MR+FX-40ER
|
Rated pressure: 6.3Mpa
|
Total power: 28KVA
|
Range: 0-22L/min
|
Voltage: AC380V 50HZ
|
System working pressure: 4-6.3Mpa
|
Overall dimension: 7500x3150x2100mm
|
Hydraulic oil: 46 wearable hydraulic oil
|
Total weight: 4500kg
|
Heating system:
|
Center height: 1000±10mm
|
Power of 1# heating oven:
1KWX12+0.7KWX2=13.4KW
|
Working time: 2-40pics/h
|
Power of 2# heating oven:
1KWX12+0.7KWX2=13.4KW
|
Mechanic system
|
Air highest temperature: 380C
|
Electric system; hydraulic system; mechanic system
|
Adopt SKT series belling mould
|
|
ZHANGJIAGANG XINDONG MACHINERY Co., Ltd is a high-tech entrreprise that specialized in researching, developing and manufacturing plastic extrusion equipments, various of pipes productiong line. It bears complete and advanced systems in developing, manufacturing and testing etc.
XINDONG MACHINERY COMPANY always insists on its business polity: " quality is life, science and technology is leading force, and customers' satisfaction is ultimate target", making effort to promote the technology and build up the world's first class brand name. The high quality single screw extrusion technology, newly parallel twin-screw extrusion technology; PVC PP-R PE(large diameter) pipe extrusion technology; HDPE winding forming technology; PVC PE double-wall corrugated pipe technology; PVC plastic sheet extrusion technology; PVC mixing system etc are all widely welcomed and accepted by domestic and overseas customer.
We consider " Exloring the highest technology in machinery industory; Creating a brilliant future in this field" as our company police. And we deeply believe that the tomorrow of XINDONG machinery will be much more brilliant.
