Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity: |
500liter Per Hour to 50000lph |
| Application: |
Wine |
Product Description
Fresh Milk and Yogurt Plate Sterilizer
The fresh milk and yoghoutr two-purpose plate type whole set sterilizing equipment is specially used for pasteurization of fresh milk and yoghourt. The plates and stainless steel pipes are made of high quality SUS304 stainless steel. The temperature of material inlet is 5C. The sterilization technology: Fresh milk 95C/15S and yoghoutr 95C/300S. The temperature of material outletis 5C/45C. The steam system adopts SPIRAXSARCO steam pressure relief valve, regulating valve and Denmarek TEMPRESS temperature sensor. The control cabinet adopts Japan FUJI temperature controller and Schneider electric components. The system has such functions an high temperature alarm and low temperature return flow, which have strictly guaranteed that all discharged materials comform to the technology parameters an required.
The equipment consists of the followings:
A. Plate type heat exchanger E. Material transporting pump
B. Material balancing tank F. Hot water generator
C. Hot water balancing tank G. Distribution cabinet
D. Hot water pump of inlet H. Temperature holding tank, stainless steel pipe, valve etc.
|
PRICE TERM |
FOB Shanghai |
|
STANDARD PACKING |
Export package suitable for long distance transport by sea & truck |
|
DELIVERY |
50 days since receipt of order |
|
PAYMENT TERMS |
30% T/T as down-payment |
|
70% T/T before shipment |
|
OFFER VALIDITY |
60 days from the date of the offer |
|
GUARANTEE |
12 months after installation & commissioning, or 15 month after delivery date |
HY-FILLING, as one of famous beverage and dairy packaging machinery manufactures in China, it is located in Zhangjiagang city which is very near Shanghai with beautiful scenery and convenient transportation. Owning the top-ranking R&D center and more than 20 senior engineers and 30 senior technicians, our products has covered all the domestic markets. Furthermore, we have exported our products all over the world, such as American, Argentina, Brazil, Russia, Poland, Turkey, Iran, South Africa, and Southeast Asia, etc, and more than 600 filling lines running all over the words till to now. We also offer our customers with the best technical plan, superior products, and perfect after-sale service to optimize the process of production, and supply our customers with reliable machinery. With persistent development, now our company is becoming larger and larger, thanks for your support and trust on our machinery. We consider "Exploring the highest technology in machinery industry; Creating a brilliant future in this field" as our company policy. And we deeply believe that tomorrow of HUAYU COMPANY will be much more brilliant.
Main Products:
1.2000-48000 BPH Mineral/Pure Water Bottling Line;
2.2000-40000 BPH Juice Bottling Line;
3.2000-40000 BPH Carbonated Beverage Bottling Line;
4.3000-40000 BPH Beer Bottling Line;
5.6000-30000BPH Aluminium Can Filling Line;
6.120-2000 Barrels/Hour 3-Gallon & 5-Gallon Filling Line;
7. Edible Oil Filling Line;
8. Aseptic Brick Packing Machine;
9. Aseptic Pouch Packing Machine (Pillow Type);
10. PET Preform Injection Machine;
11. Bottle Blow Moulding Machine;
12. Water Treatment;
13. UHT Plant;
14. Carbonating Mixer;
15. Bottle Unscrambler;
16. Film Shrink-wrapping or Carton Box Packaging Machine;
17. PA-Depalletizer;
18. Turn Key Project.
