Product Specifications
Prod Model: |
BK8113 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Operating Environment: |
0° C to 50° C at<75% R. H. |
Storage Temperature: |
20° C to 60° |
Accuracy: |
Stated Accuracy at 23° C± 5° |
Dimensions: |
148mm(H) X 105mm(W) X 42mm(D). |
Range: |
0 to 40.0mils |
Response Time: |
1 Second |
Product Description
FEATURES:
2-point calibration.
Portability and simplicity one hand operation.
Display Back-Light feature.
μ M/mils user-selective.
Auto power off function.
CE-Mark Approval.
For the ferrous material use.
SPECIFICATIONS
Display: 31/2
Digit liquid crystal display (LCD) with a maximum reading of 1999.
Low battery indication: The " " is displayed when the battery voltage drops below the operating level.
Operating environment: 0° C to 50° C at<75% R. H.
Storage temperature: 20° C to 60° C, 0 to 80% R. H. With battery removed from meter.
Accuracy: Stated accuracy at 23° C± 5° C, <75% R. H.
Auto power off: 15 seconds
Dimensions: 148mm(H) x 105mm(W) x 42mm(D).
TECHNICAL DATA:
Range | 0 to 40.0mils (0 to 1000μ M) |
Resolution | 0.1mils/1μ M |
Response Time | 1 second |
Accuracy | ± (4dgts) on 0 to 7.8mils ± (7dgts) on 0 to 199μ M± (3%+4dgts) on 7.9mils to 40mils, 200μ M to 1000μ m |
