D-Sub Connector, 9Pin, 15pin, 25pin, 36pin Right Angle
RoHS compliant
Specification
Rated load
0.5A 30V DC
Dielectric Withstand Voltage
AC 500V (50Hz) minute
Rated Current:
30V AC, DC
Contact Resistance:
30mΩ MAX
Insulation Resistance:
100mΩ MIN AT 500V DC
Life:
5000 times
Insertion and Extraction Force
3~20N
Material
Housing:
PBT UL94V-0
Contact material
Copper Alloy
Shell:
SPCC (Nickel plated)
Contact finish:
Gold finih (selective gold finish)
Package
Outer: Standard export carton (46.5*35*23.5cm) Inner: PE tray
D-Sub connector Materials:
Material. Zinc
Plating, gold /nickel/tin
High quality and reasonable price
Screw machine pin socket
Cover for DB connector
Contact plating: Gold flash or selective gold flash
We could provide all kind of hood D-SUB connector
Small order is available
Various type for choice
All products comply with ROHS standards
