Product Specifications
| Prod Model: |
ANJIA-227 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tensile Strength: |
350-550MPa |
| Diameter Range: |
0.14mm to 5.0mm |
| Zinc Coating: |
8g-300G/M² |
| Weight Per Coil: |
0.4kg to 1000kgs |
| Material: |
Low-Carbon Iron Wire |
| Cross Sectional Shape: |
Round |
| Application: |
Gabion Mesh |
Product Description
Usage: Galvanized Iron Wire are widely used in fencing, wire mesh products, nail products, products packaging,medical equipment and device, brush, tightwire, steel rope, high-pressure pipe, arts and crafts, constructionand other daily uses.
Material:Wire rod mainly include two types: #Q195 and #Q235.
Features:Antirust,Shiny silvery colour,solid,durable,versatile.
Weaving method:Steel rod coil-Wire Drawing-Wire Annealing-Rust Removing-Acid Washing-Boiling-Drying-Zinc Feeding-Wire Coiling.
Other:Packing as customer's requirement.
For the Oval wire, it is made from the common round wire, the standard specifications are as follows, special size according to the customer's requirements:
For the Oval wire, it is made from the common round wire, the standard specifications are as follows, special size according to the customer's requirements:
The features of common Galvanized Wire are as follows:
Electro Galvanized Iron Wire:
Diameter range: from 0.14mm to 5.0mm
Zinc coating can be from 8g/m ² to 15g/m²
Hot Dipped Galvanized Iron Wire:
Diameter range: from 0.5mm to 5.5mm
Zinc coating can be from 40g to 300g/m²
For the coils wire, the weight per coil can be from 0.4KG to 1000KGS as customer's requirement.=
| Size reference for Galvanized Iron Wire : |
| Wire Gauge | SWG in mm | BWG in mm | In Metric System mm |
| 8# | 4.06 | 4.19 | 4.00 |
| 9# | 3.66 | 3.76 | - |
| 10# | 3.25 | 3.40 | 3.50 |
| 11# | 2.95 | 3.05 | 3.00 |
| 12# | 2.64 | 2.77 | 2.80 |
| 13# | 2.34 | 2.41 | 2.50 |
| 14# | 2.03 | 2.11 | - |
| 15# | 1.83 | 1.83 | 1.80 |
| 16# | 1.63 | 1.65 | 1.65 |
| 17# | 1.42 | 1.47 | 1.40 |
| 18# | 1.22 | 1.25 | 1.20 |
| 19# | 1.02 | 1.07 | 1.00 |
| 20# | 0.91 | 0.89 | 0.90 |
| 21# | 0.81 | 0.813 | 0.80 |
| 22# | 0.71 | 0.711 | 0.70 |
| 23# to 34# are also available for galvanized iron wire . |
Hebei Anjia Wire Net Weaving Co., Ltd. is a manufacturer specialized in producing metal wire and metal wire mesh. It was established in 1991, and located in Anpin City, Hebei Province, factory covers an area of 72, 000 square meters, China where above 60% amount of Chinese wire meshes are produced. Through 18 years' dedicated work and consistent effort of staff, we developed fast; And now we are one of the top three companies in Anpin City. Meanwhile, we set a branch at Guangzhou, the Guangzhou office is located at Ying Long Plaza, while another factory is at Zhuliao town, which is specialized in producing the expanded steel sheet.
We provide products including the welded wire mesh, hexagonal wire mesh, stainless steel wire mesh, brass wire mesh, window screen, fiberglass mesh cloth, black iron woven cloth, expanded steel sheet, expanded aluminum sheet, barbed iron wire, razor wire, galvanized iron wire, stainless steel wire, black annealed wire, PVC coated iron wire, knotted wire mesh fence, chain link fence, fence net and so on.
Our products are sold throughout the world and welcomed by our customers due to competitive price and best price/quality ratios, and they are manufactured under strict observation of the ISO2001&2000 and the Chinese National Standards. The product brand "Anjia" and "Yong'an" have been accepted and well known in some countries. We cherish our international prestige and will continue to dedicate ourselves to provide best products and service to our customers.
Anjia established a fence net production line in Anping in 1997 in order to code with the the strong demard of our market network. Fence net is a widely used product. Absorbing the essence of European fencing system and the profound understanding of the different demand, no matter for security or beautifying, you can choose from Anjia fence net products. With rich experience of 10 years and the market proof, we become one of the major market player in this line.
We will make a better future with your support and trust. We will bing you more value with our continuous innovation and creation.
