Product Specifications
| Prod Model: |
TZ-Unit |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Bearing: |
NSK |
| OEM/ODM: |
Available |
| Registered Trademark: |
Taizheng |
| Size: |
12 Inches |
| Motor: |
Siemens |
| Installation Overseas: |
Available |
| Delivery Way: |
LCL or FCL |
| Weight: |
860kg |
| Precision: |
High Precision |
| Heating System: |
Electric |
| Demoulding: |
Automatic |
| Mould Life: |
>1,000,000 shots |
| Function: |
High Temperature Resistance |
| Warranty: |
12 Months |
| Customized: |
Customized |
| Condition: |
New |
| Automatic Grade: |
Automatic |
| Certification: |
ISO |
Product Description
Single layer wrapping machine
Application:
The machine is single-package vertical machine, the package belt (mica tape, tissue tape, aluminum foil, polyester film, etc. ) through the turntable rotation, around wrapped in the core line, with a single around the header. Is mainly used for wires, power cables, control cables, fiber optic cable and other insulation core wound package.
It is used for high frequency date cables such as DVI/HDMI/ATA/SATA/DP and completing heating and self adhesion and self adhesion process for hot shrink belt synchronously.
Remarks
Supply-side required dates and docunments(a&b provide within 7 working days after signed the contract, others attcheh when delivery)
A. Full set of equipment installation layout.
B. Water, electricity and gas supply requirements and the amount of interface.
Equipment consumables and wearing parts lists, grades and their origin, vulnerable parts of the provision of spare parts map.
Control components and electrical specifications, models list, Converter Manual.
Electrical schematics, product manual, the ultimate test books, machine operation and maintenance manuals.
Packing List.
Supply-side should provide the service as below: (after deliveryed the machine)
To arrange assistance for installation, adjustment and operating test.
Technician arranged to be guided by supplier when operating the machine
Demand-side should providing facilities and the preparation projects as below: (After deliveryed the machine)
Power source, water source, compressed-air line and related project
Not listed connector device.
Needed materials for product testing
| Machinry type | TZ-630Single-layer | TZ-800Single-layer |
| Applicable wire diameter | φ0.6mm-φ15mm | φ0.6mm-φ15mm |
| Around the package type | Concentric around the bag | Concentric around the bag |
| Pad wire diameter | ODφ250-350mm;Inside holeφ50mm | ODφ250-350mm;Inside holeφ50mm |
| Taping tension | Adjustment by specially-made spring | Adjustment by specially-made spring |
| Pay-off line axis | Customer self-made | Customer self-made |
| Take-up line axis | φ630mm | Φ800mm |
| Take-Wheel Drive | φ400mm | φ400mm |
| motor power | Three-phase 380V 2HP Frequency Control | Three-phase 380V 2HP Frequency Control |
| Towing power | 0.75KW Geared Motors | 0.75KW Geared Motors |
| Tapping rotation speed | 2500rpm | 2500rpm |
| Take-up line type | Take-Torque Motor | Take-Torque Motor
|
Dongguan Taizheng Wire Machine Co., Ltd is a professional well-know Taiwan-funded enterprises with production of wire&cable equipment in mainland China. Since built the production bases in dongguan, we have constantly absorbed many advanced technique from wire&cable equipment manufacturers at home and abroad. Our company supplys different kinds of products. High quality and favaroble price. We' Re pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
Main products including:
1. ABS/PLA filament extrusion machine
2. PVC/PE/XLPE extrusion machine
3. Silicone rubber extrusion machine
4. Plastic fiber optical manufacturing machine
5. Coaxial cable physical foaming extrusion machine
6. Chemical foaming extrusion machine
7. Teflon wire cable extruder machine
8. Multi-layer insulation wire extrusion machine
9.200-1250mm high speed bunching machine
10. Double twist machine with back twoster
11. Cantilever type stranding machine
12, bow type stranding machine
13. Frame type single stranding machine
14. High speed wire cutting machine
15. Multi-layer tapping machine
16. Automatic coiling machine
17. Various type of pay-off & take-up machine
18. Corresponding crosshead and mould die.
We providing turnkey project for over 1000 cable manufacturer all over the world, new factory built from December, 2014 was located in Humen Dongguan, with very convenient transportation to Shenzhen and Guangzhou, welcome for your visiting on us!
