Product Specifications
| Prod Model: |
ST-N10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: |
One Year |
| Size: |
116mmx75mmx16mm |
| Frequency: |
125kHz/13.56MHz |
| Support Card Type: |
Em ID/IC |
| Waterproof: |
IP67 |
| Materials: |
ABS |
| Color: |
White, Black |
| Logo Customization: |
Yes |
| Voltage: |
DC9~12V |
| Usage /Occasion: |
Bank/Hospital/Library/Company/Parking |
| Interface: |
Weigand26,Weigand34,RS232,RS485 |
Product Description
Specifications
Model |
ST-N10 |
Frequency |
125KHz,13.56MHz |
Interface |
Weigand26,Weigand34,RS232,RS485 |
Dimensions |
116mmx75mmx16mm |
Card Type |
ID: 3-15cm Proximity Range
IC:2-8cm Proximity Range |
Housing Material |
ABS+Black Resin for Water-Proof Function |
Environment |
*-25° C to 75° C Ambient Temperature, 10%-90% Ambient Humidity |
Protection Classification |
IP68 |
Power |
DC 12V Working Voltage |
Color Option |
White,Black |
Application |
Financial, bank, industrial and commercial tax, health care, insurance,
security, telecommunications, logistics, transportation, public transportation management, one-card-through, Parking System etc |
Customization |
Yes |
Warranty |
Warranty |
Installation
Using + type screw driver to loosen the screw between the panel and motherboard. And then embed the motherboard to the side wall with the plastic plug and screws.
Notice
1. Confirm the electric voltage (DC12V) and differentiate positive anode and cathode of power supply
2. When external Power is used, make sure sharing the power with Controller Box or using the same GND
3. When the distance between card reader and controller is more than 50m, please use Power Line with at least 1.5 square cm Dia, or using several parallel Network wires
Shipping way
Sea: Weight or CBM above on 100KGS, port to port service
Air: Weight or CBM above on 45KGS, port to port service
Express: DHL, TNT, UPS, FedEx, EMS, China air post for any weight. Door to door service
Payment
T/T, Paypal, Western Union
Package
1PC/box, 50PCS/carton Export Standard Package
Delivery time
5 work days within 100PCS, For more quantity, we will check the exactly delivery time upon your order quantity.
We also have more new type reader,
More Craft Option |
ST-N12 ID Reader
|
Cable length |
Standard length at 10cm
|
Frequency |
125KHz,13.56MHz
|
Interface |
ID-Weigand26
IC-Weigand34
|
Type |
2015 new type
|
STAR SECURITY TECHNOLOGIES(Shanghai)Co., Limited is a professional manufacturer of Security Products, Main products are the access control RFID reader, offline or TCP/IP network Access Controller, related access control products. Along with the RFID Cards, special mini cards, Smart label, RFID Tags, NFC tag, Also we have Special trading business on the Animal Identification, like the Glass tag(microchip), ear tag, comply with ISO11784/11785.
Since 2012, we focus on overseas market and integrate production and sales, we will try to provide most valuable products and service in our major area aiming to benefit our customer and end-users, also develop each other.
Star Security integrates designing, molding, manufacturing, testing, and finishing products. We comprise with a team of professional engineers and managers together with the sophisticated equipments for production and inspection. We have set up a standardized production workshop and a creative R&D base.
We also can OEM/ODM for a given brand and design all kinds of practical products as customers' requests, and response to the rapidly changing market quickly.
With the business philosophy of high-efficiency, preeminence, innovation and development, Star products are exporting to Europe, America, and Southeast Asia as well as other regions. Good quality products and comprehensive services have resulted in a high rate of customer satisfaction which has helped us earn a great reputation in this line of business. We will try to provide most valuable products and service in our major area aiming to benefit our customer and end-users, also develop each other.
For more about our company and our products, please contact us by e-mail, telephone...., we will try our best to do all well.
