| Supplier: | Chongqing Tengtian Group |
|---|---|
| Price: | US $ 798/Piece |
| Min Order: | 10/Piece |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | DJ150ZH |
|---|---|
| Markets: | North America,South America,Southeast Asia,Africa |
| Class: | a |
| Loading Capacity: | 500-800kgs |
| Manufacturer: | Since 2005 |
| Cargo Box: | 1600mm*1250mm |
| Ignition System: | Cdi |
| Tires: | 4.50-12 |
| Usage: | Cargo and Passenger |
| Driving Type: | Motorized |
| Body Type: | Open |
| Displacement: | 111-150CC |
| Tricycle Wheel Distance: | 1040mm |
| Certification: | ISO9001:2008 |
| Weight: | 300kgs |
| I Basic info. | Application | Goods Transport | Dimension(L*W*H) | 3m*1.3m*1.5m |
| Loading Capacity | 500-800 kg | Net weight: | 300kg | |
| Power | 8.2 | Transmission Type | Shaft Drive | |
| Design Max. Speed | ≥60 km/h | Brake Mode | Drum | |
| Fuel Tank | 12 L, Gasoline | Gearshift Control | Manual-Foot | |
| Starting System | Electric/Kick | Clutch Method | Manual-Hand | |
| Brake Operate | Manual-Hand/Foot | Color | Orange or Customize | |
| II Engine | Displacement | 150ml | Type | single cylinder,4-stroke, air-cooled |
| Compression Ratio | 9.2 | Bore x Stroke | 62 x 58mm | |
| Starting | Electric/Kick | Gearshift | Reciprocating 0-1-2-3-4 | |
| Ignition | C.D.I | Lubrication | Pressure and splash | |
| Max. power and corresponding rpm | 10.5kw/7000rpm | Max. torque and corresponding rpm | 13.5N.m/5500rpm | |
| Min. fuel consumption | ≤354g/kw.h | Min. no-load steady speed | 1500±150r/min | |
| III Configuration | Chasis & Keel | 50*100 /40*60 | ||
| Cargo box | L*W=1.60m*1.25m | |||
| Rear axle | automotive car rear axle | |||
| Steel plate | inlay, 3+2 two layers / inlay, monobloc 5 pieces | |||
| Tires | 4.5-12, three wheels interchangeable | |||
| Front shock absorber | two-arm front shock absorber, 180 drum | |||
| Battery | 9A | Carburetor | PZ27 | |
| Others | Protector | three headlights | ||
| IV Payment & Packing | Packaging method | CKD/SKD | Port Of Loading | Chongqing |
| Quantity in 20GP | 30 sets | Quantity in 40HQ | 60 sets | |
| Payment | 30% advanced payment by TT, balance should be paid before delivery. | |||
| Delivery Time | 20-25 Days after receiving advance payment. | |||


Erica Ye
Tel/Fax: +86-023-62935639
Mobile: +86-150 2313 8661
Web: www.cqtengtian.com
Chongqing Tengtian Group
Qinggang Industrial Development Zone, Bishan, Chongqing City, China
Zip: 402761
