Product Specifications
| Prod Model: |
FA-450 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Maximum Material Thickness: |
0.4mm |
| Maximum Cutter Width: |
500mm |
| Color Box Unfold Width: |
125-400mm |
| Production Speed: |
30-35 PCS/Min |
| Main Motor: |
4kw |
| Power Supply & Voltage: |
380V/50Hz (Three-Phase) |
| Maximum Pressure: |
45t |
| Slide Block: |
100mm |
| Machine Dimension (Lxwxh): |
2000X1000X1800mm |
| Total Weight: |
2500 Kg |
| Type: |
Punch |
| Thickness: |
≤20mm |
| Classification Of Wire Binding Machine: |
Saw Blade |
Product Description
Carton Binding Machine for Foil Roll
Usage and Feature:
-FA-450 Metal Blade Fixing Box Machine is used to bind and fix the metal on the aluminum foil roll color box; With this machine, not available to buy finished metal blade, just to buy jumbo roll material.
-Feeding, cutting and fixing full automatically.
-Low cost and high production.
-With safeguard system to keep operator safety.
Main Technical Data:
Maximum Material Thickness 0.4mm
Maximum Cutter Width 500mm
Color Box Unfold Width 125-400mm
Production Speed 30-35 pcs/min
Main Motor 4kw
Power Supply & Voltage 380V/50Hz (Three-phase)
Maximum Pressure 45T
Slide block 100mm
Machine Dimension (LxWxH) 2000x1000x1800mm
Total Weight 2500 kg
