| Supplier: | Jiangsu Zhuhong Forging Co., Ltd. |
|---|---|
| Price: | US $ 569/Piece |
| Min Order: | 15/Ton |
| Quantity:: | |
| Trade Terms: | FOB,CFR,CIF |
|
|
| Prod Model: | Casting Round C55Cr |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: | Casting Round C55cr |
| Place Of Origin: | Wuxi,China |
| Rangeof Size: | 130mm-800mm |
| Length: | by Request |
| Weight: | Customized |
| Tolerance: | -0/+2mm for Size and -0/+20mm for Length |
| Surface: | Polished |
| Heat Treatment: | by Request |
| Ultrasonic Test: | Sep1921-84 Class C/C, D/D |
| Marking Color: | by Request |
| Type: | Carbon Steel Bar |
| Standard: | BS |
| Steel Grade: | 400 Series |
| Technique: | Forged |
| Application: | Shipbuilding Industry |
| Surface Treatment: | Polished |
| Alloy: | Non-alloy |
| Special Use: | Cold Heading Steel |
| C | Si | Mn | P | S | Cr | Ni | Mo | Cu | Al | V |
| 0.52/0.58 | 0.17/0.35 | 0.6/0.8 | <=0.03 | <=0.03 | 0.3/0.4 | <=0.25 | <=0.1 | <=0.2 | 0.02/0.05 | <=0.05 |
| Material: | C55Cr forged steel round bar |
| Process: | Forged from vacuum degassed ingots. |
| Diameter: | 130mm-1000mm (optional) |
| Length: | 1000mm-12000mm Straightness: 3mm/M max(optional) |
| Process: | EAF + LF + VD + Forged + Heat Treatment (optional) |
| Delivery condition: | Hot forged +Rough machined (black surface after Q/T)+ Turned (optional) |
| Delivery Time: | 30-45 days |
| MOQ: | 20 tons |
| Heat treatment: | Normalized / Annealed / Quenched / tempered (optional) |
| Technical Data: | According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing |
| Properties: | As your request |
| Test: | Ultrasonic test according to SEP 1921-84 Class C/c and D/d (optional) |
| Marking: | Grade, heat NO. length will be stamped one each bar with required color |
| Payment: | 30% advance by T\T; Balance pay before the shipment against shipping documents or irrevocable LC at sight |
| similar steel grade | 55#/45#/60# |
| Application: | Statically and dynamically stressed components for vehicles, engines and machines. For parts of larger cross-sections, crankshafts, gears. |
