Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5e requirements.
Meet TIA/EIA TSB-40
Meet ISO/IEC Generic Cabling Standard 11801
Meet CENELEC Generic Cabling Standard EN50173
Angle: 90 Degree
Termination: 110&Krone Type
Electrical:
According to UL 1863
Current rating: 1.5 AMP Max.
Voltage rating: 150 Volts
Contact resistance: 20 m-ohm
Insulation Resistance: 500M-ohm
Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min
Materials:
Housing: PC UL94V-0
IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.
PCB: FR4 1.6mm(0.04") thickness, 2 layers
Contact: PC UL94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 u" to 50 u" Gold plating on contact area
Shenzhen DRJ Network Products Co., Ltd., is a professional company who bends itself to futurity network transmit R&D and application. As a specialty structured cabling system manufacturer, we owns a top ranked experienced R&D team, meanwhile, we're working closely with the summit network manufacturer in the world, now being jump as a global leading supplier of end-to-end network cabling solutions.
Our mainly networking product covers: LAN Patch Cord, Communications cable, Patch panel, Keystone Jack, Faceplate and Cable management, also providing the whole solution of Fiber transmission system. Our products meet the international standard of UL listed, CE verified, ETL approval, RoHS compliance, in order to ensure all products shows excellent performance and quality. At present, our products have been widely applied to location such as office building, school, government building, military affairs university and harbor.
Our aim to be a worldwide excellent ODM partner for multi-national companies, working hard to providing the high quality level networking products to the human being.
Welcome to establish partnership with our company, please contact us in order to get more the latest product information.
