Product Specifications
| Prod Model: |
CBB65 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
Capacitor |
| Rated Voltage: |
220V |
| Operating Temperature: |
-40/+85/21 |
| Material: |
Aluminum |
| Capicator: |
4~30 UF |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
Air Conditioner |
| Package Type: |
Surface Mount |
| Capacitance: |
1-50uf |
| Usage: |
Air Condeitioner System |
Product Description
cbb65 AC motor run capacitor :
1.Used widely in motors,air conditioner ,water pump etc.
2.High performance & Long life.
3.Work well even in hot area.
4.We can producs according to customer's requirement.
CBB65 capacitor Technical Specifications:
Standard: IEC 60252-1:2001
Climate type:40/70/21 or 40/85/21
Capacitance range:2MFD-100MFD,15+5MFD-80+7.5MFD
Capacitance tolerance:± 5%
I.R:≥3000S(MΩ.μF)
CBB65 capacitor Dielectric dissipation factor:
tgδ≤0.002 (50Hz~100Hz)
Application requirements:
Altitude:≤2000m
Residual voltage while loading: less than 10% of rated voltage.
Allowed maximum voltage: less than 1.1 times of rated voltage
Permissible maximum current: less than 1.3 times of rated current.
CBB65 capacitor Dimensional specification (mm):
1.Rated voltage(VAC):200,250,370,400,440,450,480.
2.Nominal capacitance (MFD) :More than 1μF
3.Size(mm) (1).D: 40,45,50,55,60,70,80,100,25+5,30+5, 35+5,50+5.
(2).H: 60,65,70,75,80,85,90,95,100,105,110,115,120,125,135,138.
Any question pls feel free to contact us at any time.
Best regards
Betty
Model |
Size |
Model |
Size |
CBB65/450V |
5UF |
40*55 |
CBB65/450V |
20+1.5UF |
50*75 |
|
7.5UF |
40*55 |
|
20+5UF |
50*85 |
|
10UF |
40*65 |
|
25+1.5UF |
50*85 |
|
12.5UF |
40*65 |
|
25+3UF |
50*90 |
|
15UF |
40*75 |
|
25+5UF |
50*100 |
|
17UF |
40*75 |
|
30+2UF |
50*100 |
|
20UF |
45*75 |
|
30+5UF |
50*100 |
|
25UF |
45*100 |
|
30+7.5UF |
50*105 |
|
25UF |
50*75 |
|
35+2UF |
50*105 |
|
30UF |
45*100 |
|
35+5UF |
50*105 |
|
30UF |
50*85 |
|
35+7.5UF |
50*105 |
|
35UF |
50*100 |
|
40+5UF |
50*105 |
|
35UF |
50*85 |
|
40+5UF |
50*120 |
|
40UF |
50*100 |
|
40+7.5UF |
50*120 |
|
45UF |
50*100 |
|
45+5UF |
50*120 |
|
45UF |
50*110 |
|
45+7.5UF |
50*120 |
|
50UF |
50*100 |
|
50+5UF |
50*120 |
|
50UF |
50*110 |
|
50+7.5UF |
50*125 |
|
50UF |
50*120 |
|
55+5UF |
55*125 |
|
55UF |
50*110 |
|
55+6UF |
55*125 |
|
60UF |
50*125 |
|
55+7.5UF |
55*125 |
|
65UF |
50*125 |
|
60+5UF |
55*125 |
|
70UF |
55*125 |
|
60+6UF |
55*125 |
|
80UF |
55*125 |
|
60+7.5UF |
55*125 |
|
100UF |
60*125 |
|
65+5UF |
55*125 |
CBB65/370V |
5UF |
40*55 |
CBB65/370V |
20+1.5UF |
50*75 |
|
7.5UF |
40*55 |
|
20+5UF |
50*85 |
|
10UF |
40*65 |
|
25+1.5UF |
50*85 |
|
12.5UF |
40*65 |
|
25+3UF |
50*90 |
|
15UF |
40*75 |
|
25+5UF |
50*90 |
|
17UF |
40*75 |
|
30+2UF |
50*90 |
|
20UF |
45*75 |
|
30+5UF |
50*95 |
|
20UF |
40*75 |
|
30+7.5UF |
50*105 |
|
25UF |
50*75 |
|
35+2UF |
50*105 |
|
25UF |
45*75 |
|
35+5UF |
50*105 |
|
30UF |
45*85 |
|
35+7.5UF |
50*105 |
|
30UF |
45*100 |
|
36+2UF |
50*100 |
|
30UF |
50*75 |
|
36+4UF |
50*100 |
|
35UF |
50*85 |
|
36+6UF |
50*100 |
|
35UF |
45*85 |
|
40+5UF |
50*120 |
|
35UF |
50*100 |
|
40+7.5UF |
50*120 |
|
36UF |
50*95 |
|
45+2UF |
50*105 |
|
40UF |
50*85 |
|
45+4UF |
50*105 |
|
40UF |
50*100 |
|
45+5UF |
55*110 |
|
45UF |
50*100 |
|
45+6UF |
50*105 |
|
45UF |
50*110 |
|
45+5UF |
50*125 |
|
50UF |
50*100 |
|
45+7.5UF |
50*125 |
|
50UF |
50*110 |
|
50+2UF |
50*105 |
|
55UF |
50*100 |
|
50+4UF |
50*105 |
|
55UF |
50*110 |
|
50+5UF |
50*125 |
|
60UF |
50*110 |
|
50+6UF |
50*105 |
|
60UF |
50*125 |
|
50+6UF |
50*125 |
|
70UF |
55*125 |
|
50+7.5UF |
50*125 |
|
80UF |
55*125 |
|
55+5UF |
50*125 |
Packaging |
In seaworthy cartons. |
Delivery Detail: |
10-15 days after your payment. |
