Product Specifications
| Prod Model: |
VR8800N |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Colour: |
Black |
| Shell Material: |
Aluminium Alloy |
| Export Market: |
All Over The World |
| Certificate: |
CE/FCC/RoHS |
| Application: |
Security Monitoring(Bus, Car, Ship etc) |
| Style: |
Clamshell with TFT and Lock |
| Unit Dimension: |
180mm(L)*50mm(W)*194mm(H) |
| Memory Storage: |
HDD & SD Card |
| Compression Format: |
H.264 |
| Interface: |
BNC\VGA\HDIM |
| Brand: |
DTY |
Product Description
Features
1. Metal design, with cooling fan to avoid overheating;
2. Immediately gets into "Preview Mode" once turned on;
3. Supports Manual Record & Motion Detect & Boot Record;
4. Supports Scheduled Record, records according to a full 24 hours schedule;
5. Video resolution up to D1/channel(NTSC 720*480/30FPS; PAL 720*576/25FPS);
6. Records 4CH video & 4CH audio at the same time;
7. Supports web real-time remote monitoring;
8. Both supports 2.5" Sata HDD up to 4TB and 64GB SD card;
9. With shell lock, user password to keep the data safe;
10. Data can be easily backed up to your PC via the USB2.0 port;
11. With Date/Time and ID stamped on the screen;
12. Easy installation; Easy operation and free maintenance;
13. With IR remote control, will help operate the device easily;
14. Can be connected with 4 cameras, and are able to power the 4 cameras directly;
15. Can connect mouse to operate the menu;
16. Can connect USB to back up files.
17. With 3G GPS Function
Technical Parameters
Model: VR8800-3G(V4.1)
Working Voltage DC 12-36 V (DC 14-36 V when connected with cameras)
Output Voltage (for camera) DC12 V
Power Supply Car battery
Maximum Memory Capacity 4TB & 64GB SD card
Compression File Format H. 264
Record Switch Continuous record or motion detect
Record mode Motion detect, scheduled record and boot record
Record Quality D1 per channel
Resolution D1 (PAL 720*576, NTSC 720*480)
Frame Rate PAL (1~100fps) NTSC (1~120fps)
Record AV in signal 4 CH video+4 CH audio
File Store Mode Overwrite when full or stop when full
Alarm Input/Output 4 alarm input & 2 alarm output
Internet Interface One 10M/100M RJ45
HDD Interface One 2.5 inch SATA HDD interface
Compatible camera Common CMOS & CCD
Dimension: 210mm*180mm*50mm
Net weight: 950G
|
Model |
Function |
|
VR8800N |
Basic Model----4CH Full D1 Real Time Recorder |
|
VR8800 |
VR8800N+3.5"TFT |
|
VR8800GW |
VR8800N+3.5"TFT+GPS+WIFI |
|
VR8800-3G |
VR8800N+3.5"TFT,+GPS,+3G |
|
VR8800W |
VR8800N+3.5"TFT,+WIFI |
|
VR8800-3GW |
VR8800N+3.5"TFT,+GPS,+3G+WIFI |
