Cdp Low Frequency 1 Phase in 1 Phase out UPS

Name: Cdp Low Frequency 1 Phase in 1 Phase out UPS
Brand: china-manufacturer-directory.com
SKU: 775140485
Availability: InStock
Rating: 4.8 (95 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

CDP series are 1 phase in 1 phase out UPS. Their capacity range from 7.5KVA to 30KVA. These series have applied full digital control technology based on DSP (digitalized signal processor). High efficiency transformation endures high power current and high voltage with an extremely low consumption. The machine can run self-diagnose, and with standard RS232 for SNMP or RS485 cards, they are conveniently managed by central monitoring and remote monitoring. The latest Redundancy Parallel Array technology is available with these series. RPA function can operate on up 32 units.

Product Features

1.Applying full digital control technology based on DSP
2.The shift time between Invertion and bypass is less than 1 millisecond.
3.AC start (cold start), convenient to operate
4.Auto re-start function
5.Complete protection and alarm functions, MCU is monitoring all circuits and detecting bugs during the long run
6.Extremely wide input voltage range
7.Self-diagnose function
8.Isolated output transformer islotated the electricity shock from various loads
9.Most advanced RPA functions allow up to 32 units of machines to be working in the parallel array

MODEL	CDP-2K/P	CDP-3K/P	CDP-5K/P	CD-6K/P	CDP-7.5K/P	CDP-10K/P	CDP-15K/P	CDP-20K/L	CD-30K/L	CDP-40K/L
Rated Power	1.6KW	2.4KKW	4KW	4.8KW	6KW	8KW	12KW	16KW	24KW	32KW
INPUT
Rated Voltage	single phase 220V±25% or 110V±25%
Frequency	50 Hz/60Hz ±5%(optional ±10%)
Power Factor	3KVA	4.5KVA	7.5KVA	9KVA	11.3KVA	15KVA	22.5KVA	30KVA	45KVA	60KVA
OUTPUT
Rated Voltage	single phases 220V±1%
Frequency	50/60Hz±0.5% (inverted tense)
Waveform Distortion	Pure sine wave, distortion ≤2.5 as with linear loads, while ≤3 as with non-linear loads (when full load)
Imbalance of parallel	current <5%
Overload Capacity	Over load 120% can last 10 minutes, over load 150% can last 20 seconds
Wave Crest Coefficient	5:1(full loading)
BATTERY
Rated Voltage	192VDC
Battery Nos.	12Vdcx32 nos.
Battery Voltage	12 Vdc (15-20 nos adjustable)
Back-up Time	Extra battery(back-up time is determined by battery capacity)
Back-up Time for battery built-in type	Battery built-in type, use 12V/7AH VRMF lead acid battery
Back-up Time for battery built-in type	13 min	8 min	6 min	5 min	N/A
System
Transfer Time	AC←→battery 0 ms;Inverter←→bypass < 4 ms
Ingress Protection	IP20
Conversion Efficiency	≥85%(full loading)
Noise	50db(1 meter)			53db(1meter)				55db(1meter)
ENVIRONMENT
Temperature	0ºC~45ºC
Humidity	0~93% RH,non-condensing
Altitude	<1500m
Size
W×D×H(mm)	260×620×625						410752941
Weight
N. Weight (kg)	75/45	80/50	95/60	100/65	85	95	127	142	210	240
G. Weight (kg)	85/55	90/60	105/70	110/75	115	125	170	220	265	280

Prod Model:	CDP
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Capacity:	2kVA to 30kVA
Charateristic1:	Digitalized Signal Processor
Charateristic2:	Run Self-Diagnose
Charateristic3:	with Standard RS232 for Snmp or RS485 Cards
Charateristic4:	Managed by Central Monitoring and Remote Monitorin
Phase:	Single Phase
Type:	On-line
