Pure Sine Wave Inverters produce exactly the same type of power wave that is provided by the national grid (mains power).
Making them ideal for use with sensitive and specialised equipment. These Inverters are generally more expensive but are
Considered essential for use with certain products for example; Oxygen concentrators, fax machines, laser printers, high voltage
Cordless tool chargers, equipment with variable speed motors, electric shavers, and garage door openers. Other products such
As high-end audio video units, plasma displays, TV's, gaming systems, and certain scientific testing equipment, may work fine
With Modified Sine Wave power but might benefit in performance from the use of a Pure Sine Wave Inverter.
1. Approvals: CE mark / EMC / LVD/ RoHS
2. Output wave form: Pure sine wave output (THD<3%)
3. Power ON-OFF switch
4. Thermo control cooling fan
5. Two-color indicators display power and fault status
6. Max efficiency to 92.5%
7. Topology: Microprocessor
8. Low battery voltage, over battery voltage, lack-voltage alarm. Protections: Short circuit, overload, over temperature,
Applications:
You can use many place. Such as laptop, camcorder, the Internet, GPS, camera, PDA, cell phone, mobile DVD, audio, battery charger, printers, monitors, game consoles, trucks, etc.
1. Field operations: Lighting, drilling, disaster relief, commercial promotions.
2. Hospital emergency rescue: Surgical lighting, equipment use, etc.
3. Home Appliances: Electronic energy-saving fluorescent, incandescent, small television sets, car refrigerator, etc.
Socket type (When you make order, please let me know your choose, thanks! ! ):
Model
|
WOSN-2500W
|
Input
|
DC Voltage
|
12V/24V or48V
|
Voltage Range
|
11-15V DC or22-30v/44-60V
|
No Load Current Draw
|
<3A
|
Efficiency
|
> 90%
|
DC Connector
|
Cables With Clips or Car Adaptor
|
Output
|
AC Voltage
|
100 V or 110VAC/ 120v AC/AC220V or 230V or240V
|
Continuous Power
|
2500W
|
Peak Power
|
5000W
|
Waveform
|
Pure Sine Wave
|
Frequency
|
50HZ/60Hz
|
AC Regulation
|
3%
|
Protection
|
Low Voltage Alarm
|
DC10.2-10.8V /20.4-21.6V/40-43.2V
|
Low Voltage Shut Down
|
9.2-9.8VDC /18.4-19.6VDC/36-38VDC
|
Over Load
|
Shut Off Output
|
Over Voltage Shut Down
|
15.5V /31v/62v
|
Over Thermal
|
Shut Off Output Automatically
|
Fuses
|
Short Circuit
|
Environment
|
Working Temperature
|
Between -5 and +40
|
Working Humidity
|
10%~90%RH
|
Storage Temperature
|
Between -20 and +50
|
Package
|
Machine Size(mm)
|
435*199*73
|
Packing Size(mm)
|
47*23.5*13.5cm
|
Net Weight(kg)
|
5.6KG
|
Gross Weight(kg)
|
7KG
|
Packing Mode
|
Carton
|
Other
|
Start
|
Soft Start
|
Cooling Ways
|
Cooling Fan
|
