Shanghai Saipwell Electric Co., Ltd. >> CE Approved Mini Circuit Breaker (SPM2-100L)

CE Approved Mini Circuit Breaker (SPM2-100L)

Name: CE Approved Mini Circuit Breaker (SPM2-100L)
Brand: china-manufacturer-directory.com
SKU: 737447765
Availability: InStock
Rating: 4.8 (135 reviews)

Supplier:	Shanghai Saipwell Electric Co., Ltd.
Price:	US $ 16.9-19.5/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	SPM2-100L
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Circuit Breaker
Shell Grade Rated Current:	100
Rated Current:	(10),16,20,25,32,40,50,63,80,100
Rated Operational Voltage:	AC400
Rated Insulation Voltage:	AC690
Rated Short-Circuit Breaking Capacity:	22ka
Rated Ultimate Short-Circuit Breaking:	35ka
Warranty:	2 Years
Service:	OEM
Port:	Shanghai/Ningbo
Arc-extinguishing Medium:	Air
Structure:	MCCB
Breaking Capacity:	Low Voltage Circuit Breakers
Poles Number:	3
Certification:	IEC
Operation:	Energy-storage Type
Installation:	Open Frame
Speed:	High-Speed Circuit Breaker

Product Description

High Quality Circuit Breaker (SPM2-100L)

Features of the Circuit Breaker:
1. Reasonable design: Safe and reliable performance, compact volume, light weight, elegant appearance.
2. Complete accessories, convenient installation, easy use, wide applicability.
3. SPM2 series moulded-case circuit breaker is one of the new type circuit breakers researched and developed by our company by adopting international advanced design and masnufacturing technoligies.
4. It can be divided into L type (Stand type), M type (second high breaking type) and H type (high breaking type) three types according to its rated ultimate short-circuit breaking capacity.
5. The products are featured with compact volume, high breaking capacity, short flashover, vibration proof, etc

Packaging&Shipping of the Circuit Breaker:
Packaging detail: Standard export packing
Shipping detail: Within 5 days after getting payment

Our service:
Inquiry: Always reply in 24 hours.
Shipment: Sea transportation, air transportation or express, fast delivery.
Payment: T/T Advance, L/C 100% Payment if total amount less than $10, 000USD.
Warranty: 2 years.
We provide best OEM service.

About us:
Saip Electric Group Co., Ltd., is an enterprise specialized in design, production and sales of electric equipment. Had office is located in the largest manufacturing base of electric equipment of Wenzhou China.
Business Type: Manufacture
Main Products: Instruments & Meters, Lights & Lighting, Electrical & Electronics, Industrial Equipment & Components
Saip always inherits the principle---- "high quality and sincere service", bearing the aim to create products that brings happiness.
Thanks for your view, welcome to visit our website: www.saipwell.com

Type	Shell Grade Rated Current	Rated Current	Rated operational Voltage	Rated insulation Voltage	Rated ultimate short-circuit breaking capacity(KA)400V	Rated short-circuit breaking capacity(KA)400V
SPM2-63L	63	(10),16,20,25,32,40,50,63,80,100	AC400	AC690	25	18
SPM2-63M					50	35
SPM2-100L	100	(10),16,20,25,32,40,50,63,80,100	AC400	AC690	35	22
SPM2-100M					50	35
SPM2-100H					85	50
SPM2-225L	225	100,125,140,160,180,200,225	AC400	AC690	35	22
SPM2-225M					50	35
SPM2-225H					85	50
SPM2-400L	400	225,250,315,350,400	AC400	AC690	50	35
SPM2-400M					65	42
SPM2-400H					100	65
SPM2-630L	630	400,500,630,	AC400	AC690	50	35
SPM2-630M					65	42
SPM2-630H					100	65
SPM2-800M	800	630,700,800	AC400	AC690	75	50
SPM2-800H					100	65
