Product Specifications
| Prod Model: |
Q37 Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Q37 Series |
| PLC: |
Simens or Omron |
| Co: |
BV ISO SGS |
| Delivery: |
45 Days |
| Style: |
Hanging Style |
| Physical Machine Type: |
Mechanical Cleaning Method |
| Clean Type: |
Shot Blasting |
| Export Markets: |
Global |
| Color: |
Blue or Gray or Optional |
Product Description
Hanger Hook Shot Blasting Machine
1.Abrator description
The abrator is designed for surface cleaning and hardening of variety and small quantities of castings, forgings and steel profiles to remove attached green sand, core sand and scale.
It is also fit for the surface cleaning and hardening of heat treated parts,especially for brittle,long thin-section parts.
2. Specifications of the abrator
A. Increasing the anti-fatigue properties of mechanical product and metal components.
B. Removing stress concentration
C. This machine use manual operation control system, and all components are famous brand in China.
D. This machine uses most advanced full shutter type air wash separator (DISA technology).
E. Safety limit switch. When the cover of blast wheel is open, the machine cannot be started
F. 10mm thickness SPMn13protective liner, lifetime is about 15000 hours
G. PLC control systerm , can achieve automatic operation .
3.Structure of the abrator
The machine is consists of shot blasting room, elevator, separator, screw conveyor, two pieces of impeller head assembles, abrasive control system, hook track, hook system, auto rotation device, foundation, dust collecting system and electrical control system, etc.
4.Technical Specification
Item | Q376 | Q378 | Q3710 | Q3720 | Q3750 |
| The maximum size of workpiece | φ600*1100 | φ800*1500 | φ900*1600 | φ1400*2300 | φ1800*2500 |
| Each hook capacity (kg) | 600 | 1000 | 1000 | 2000 | 5000 |
| Shot blasting rate (kg/m) | 2*120 | 2*180 | 2*250 | 2*250 | 2*250 |
| Lifting capacity (t/h) | 15 | 12 | 30 | 45 | 60 |
| Fractional dose (t/h) | 15 | 22 | 30 | 45 | 60 |
| Blast volumeof Dust Elimination (m3/h) | 5000 | 8000 | 9000 | 15000 | 18000 |
If the above model not suit for your work piece, please tell me your need and the following information then we will send you the best technical drawing to you.
1. The max. Length of the work piece.
2. The max. Width of the work piece.
3. The max. Height of the work piece.
4. The product you need to blast the work piece (how many T or piece per day or per month?)
5. The power supply you need (such as 380V, 3P, 50HZ)
6. Better to send us the work piece photo or drawing.
FAQ
Q: What standards are you carrying out for your products?
A: We produce according to the ISO9001 and ISO14001 rules.
Q: How to install the machine?
A: We will arrange 1~2 engineers to your factory to guide installation and assembly.
Q: What's your international market?
A: We Have exported to about 40 countries and regions all around the world, such as, the USA, France, Singapore, Australia, Middle East, Brazil, Peru and so on.
Q: What's your productivity?
A: We have three production lines for steel shot and steel grit production, one work shop for steel cut wire shots, and one workshop for stainless steel shot and Aluminium shot and so on.
Our Services
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in time.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory: We are manufacturer, specializing in producing all kinds of Shot Blasting Machine & Molding Machine & Core Shooting Machine for more than 40 years, competitive with good quality.
7. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature.
If the above model is not suitable for your workpiece, please tell us your need and then we can send you the most satisfying drawing.
