Product Series
CASTLE
Model
C1K
C2K
C3K
Rated Power
VA/W
1kVA / 0.7kW
2kVA / 1.4kW
3kVA / 2.1kW
Input
Nominal Voltage
220VAC
Voltage Range
115 ~ 300VAC
Frequency Range
46~54Hz(default), user adjustable within 40~60Hz
Power Factor
0.97
Connection
IEC320-10A inlet
IEC320-16A inlet
Output
Voltage
220VAC ± 2%
Frequency
46~54Hz or 50Hz ± 0.2Hz (Line mode)
50Hz ± 0.2Hz ( Battery mode)
Waveform
Sine Wave
Distortion
3%
4%
Overload Capability
108%~150% for 30 sec., ³ 150% for 300 ms
Current Crest Ratio
3: 1
Connections
IEC320 * 4
IEC320 * 6
IEC320 * 3 and
Terminal Block
Battery
Type
Sealed, Maintenance free, Lead-Acid
Quantity
3 pieces
8 pieces
Back-up Time (Full load)
5 min
9 min
5 min
Recharge Time
5 hrs to 90% of capacity after full load discharge
Bypass
Automatic Transfer
On overload and UPS failure
Before UPS Power-on
Default "NO", user adjustable to "YES"
Voltage Range
80~264VAC (Default), user adjustable within 80~286VAC
Transfer Time
0 ms; Less than 4 ms from inverter to bypass and vice versa
LED Indicators
Status
Load level / Battery level, Battery, Utility Power, Inverter, Bypass, Overload, Fault
Audible Alarm
Bypass, On battery mode, Battery low, Overload, Fault
Acoustic Noise
At 1 meter distance
45 dBA
50 dBA
Communications
dB-9 Port
RS-232 Serial Interface
Intelligent Slot
Options: WebPower, AS400 Card or WinPower CMC
Network Surge Protection
RJ45 I/O port available for network or Fax/Modem
Environmental
Operating Temperature
0 ~ 40° C
Operating Humidity
20 ~ 90% non-condensing
Weight
Net (Kg)
13
31.5
32
Dimensions
W x D x H (mm)
145 x 400 x 220
192 x 460 x 348
Model
C6kVA/C6KS
C10kVA/C10KS
Rated Power
VA/W
6kVA/4.2kW
10kVA/7kW
Input
Nominal Voltage
220VAC
Voltage Range
176 ~ 276VAC
Frequency Range
46 ~ 54Hz
Power Factor
0.98
Connection
Hardwired
Output
Voltage
220VAC ± 1%
Frequency
50Hz ± 0.1% ( Battery mode)
Waveform
Sine Wave
Power factor
0.7
Voltage Distortion
2% under linear load
Overload Capability
105% ~ 130% for 10 min., ³ 130% for 1 min.
Current Crest Ratio
3: 1 max.
Connection
Hardwired
Battery
Type
Sealed, Maintenance free, Lead-Acid
Quantity
20 pieces
Back-up time (full load)
7 min
5 min
Recharge time
8 hrs to 90% of capacity after full load discharge
Transfer time
0 ms
Maintenance Bypass Switch
Yes
LED indicators
Status
Load level/Battery level, Battery, Utility power, Inverter, Bypass, Overload, Fault
Audible alarm
Bypass
Alarm beeps every two minutes
Battery discharge
Alarm beeps every four seconds, every second if battery low
Overload
Alarm beeps two for every second
Fault
Alarm beeps continuously
Acoustic noise
At 1 meter distance
55 dBA
Communications
dB-9 Port
RS232 serial interface
Intelligent Slot
Options: WebPower, AS400 or WinPower CMC
Parallel Port
Up to three units in parallel for power redundancy and load sharing
Environmental
Operating temperature
0 ~ 40° C
Operating humidity
20% ~ 90% non-condensing
Weight
Net (kg)
35/84
38/93
Dimensions
W x D x H (mm)
260 x 570 x 717
