Product Specifications
| Prod Model: |
CH100(A) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Blending Machine |
| Model: |
CH100(a) |
| Trough Capacity: |
100 L |
| Miaing Arm Speed: |
24r/Min |
| Main Motor: |
2.2kw |
| Certification: |
ISO |
| Finished Dosage Form: |
Powder & Granule |
Product Description
Main Application:
As a whole stainless horizontal tank type mixer (blender), this CH100(A) Blending machine is widely used for mixing of powdery or paste material in pharmaceutical chemical and foodstuff industries.
Working Principle:
S type agitiating paddle is rotated, through mechanical driving, which pushes the material turn repeatedly and mix uniformly. Operate with electrical control, CH100(A) Blending machine can set mixing time to realize automatic stop and electric discharge upon expiration, thus improving the mix quality of each batch of material and realizing the high homogeneous mixing.
|
TYPE |
CH100(A) |
|
Trough capacity(L) |
100 |
|
Miaing arm speed(r/min) |
24 |
|
Tilting angle of the trough |
105 |
|
Main motor(KW) |
2.2 |
|
Overall dimension(mm) |
1480*685*1125 |
|
Weight(kg) |
350 |
Yangzhou Nuoya Machinery Co., Ltd is a scientific and technological enterprise which incorporates development, manufacture and correlation service from pharmaceutical machines, food machines and chemical machines into an organic whole.
The main products: Equipments used for troche & Capsule production line. Including: Tablet press, capsule filling machine, blister packing machine, mixer, pulverizer, granulator, dryer and so etc.
Our company has strong technical force and production experience, the first through the IS09001 international quality system certification, and has a number of patents and inventions, to fill the domestic blank, identified by the national authoritative organization; Products are all in line with the GMP requirements, Most products have successfully passed the European CE certification and SGS certification.
NOAH' S human integrity & dedication, through hard work and struggle for many years, so our products has become a symbol of high quality, with a large number of domestic and foreign customers, selling more than 60 countries and regions.
We appreciate every trust and support, and would like to cooperate with you to create good future.
