Changlin Wheel Loader 933 3tons Loader with Good Price

Name: Changlin Wheel Loader 933 3tons Loader with Good Price
Brand: China-Manufacturer-Directory.com
SKU: 718888505
Availability: InStock
Rating: 4.3 (132 reviews)

Supplier:	Guangzhou Dekun Construction Machinery Co., Ltd.
Price:	US $ 1-10/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Bucket Capacity:	1.4-3.2 Cbm
Rated Load:	3tons
Operating Weight:	10200kg
Lifting Time:	5.1 S
Lowering Time:	3 S
Dumping Time:	1.1 S
Walking Mode:	Wheeled
Condition:	New
Type:	Small Loader
Certification:	ISO9001: 2000
Load And Unload Method:	Disable The Cab and Bucket

Product Description

The features of 933 wheel loader 3 tons:

1) Using the new engine Yuchai engine, powerful, low oil consumption.

2) Dual variable system uses a unique sub-structure, easy maintenance, smooth transmission of power.

3) Gearbox transmits power performance and strength, reliability, superior general 3 tons loader, gears adopt flexible shaft manipulation, more accurate, and lightweight.

4) Hydraulic mechanical transmission, automatic adjustment, infinitely variable.

5) The sum of three time is short, handling more material, high efficiency ---- Σ T = t1 + t2 + t3=9.2s.

Main Specification	Units
Bucket capacity	m3	1.4-3.2
Rated load	kg	3000
Max.digging force	kN	96
Max.travelling force	kN	96
Operating weight	kg	10200
Overall dimension(LWH)	mm	686324623095
Engine
Engine model		Yuchai YC6B125-T20
Type		Vertical, four-stroke, direct injection
Rated power	kw	92
Rated speed	r/min	2200
Min.fuel consumption	g/kW.h	Less or equal to 235
Max.torque	N.m	40
Transmission system
Torque converter type		Single stage,single phase,three elemenrs
Cooling ways		Oil cooling,pressure circling
Transmission type		Spur gear parallel shaft ,constant-mesh
Traveling speed (F3+R3)
IForward gear	km/h	7.3
IIForward gear	km/h	15.7
IIIForward gear	km/h	35
IReverse gear	km/h	7.8
IIReverse gear	km/h	16.8
IIIReverse gear	km/h	36
Steering system
Type		Middle articulated frame ,Co-axls flow amp.steering
Steering angle		±38°
Min steering radius	mm	4980
Displacement of redirecter	ml/r	400
Mode of steering pump		Gear pump
Steering cylinders inner Bore*Stroke		2-Φ70*323
Operation pressure	MPa	14
Working hydraulic system
Type		Shaft control
No.of Cylinder-Bore*Stroke
Lift cylinder		2-Φ125*697
Dump cylinder		1-Φ150*434
Multi-way valve		Hydraulic multi-valve
System operation pressure	MPa	16
Lifting time	s	5.1
Lowering time	s	3
Dumping time	s	1.1
Tyre
Standard tyre		17.5-25-12PR
Tyre pressure	MPa	0.275-0.294
Refill Capacity
Fuel tank	L	130
Engine crank case	L	17
T/C & Transmission	L	35
Hydraulic oil tank	L	120
Axle main drive	L	2*11
Hub reduction	L	4*1.5
Brake system	L	2*0.5
Work equipment
Strong Z-bar structure provides strong breakout force
Dumping clearance (at dumping angle 45°)	mm	2850
Dumping reach (at dumping angle 45°)	mm	1030
Max.dumping reach	mm	3735

Guangzhou Dekun Construction Machinery Co., Ltd was set up in 2009. We are a company engaged in Construction Machinery, Heavy Duty Machinery and Agricultural Machinery.
The products of our company are available through the Manufacturer's Authorized, Product Quality, ISO9001 Quality System Certification and CE Certification.
The company provides Wheel Loader, Skid Wheel Loader, Road Rollers, Bulldozers, Excavators, Motor Grader, Paving Machine, Truck Crane, etc.
Products are exported all over the world by continuous exploration and development. Now establish good working relationship with many foreign customers, Iran, Iraq, Saudi Arabia, Kuwait, and Brazil, etc.
