China 10W Fiber Laser Marking Machine with Laptop, Cheapest 10W Portable Fibre Laser Marking System for Metal Sheets
Product Specifications
| Prod Model: |
ls1509011 |
| Type: |
Energy Meter |
| Display: |
Digital |
Product Description
The optical fiber laser marker is the third generation laser marker system developed by our company with the most advanced technology in the world. It uses optical fiber laser to output laser and realizes marking function through high speed scanning galvanometer system. The optical fiber laser marker features high electro optic conversion efficiency, air cooling, small size, high quality output beam, high reliability, long service life and energy saving. It can carve metal materials and certain nonmetal materials and is widely used in fields that have high requirement on depth, smoothness and fine, such as stainless steel mobile phone overlay, clock and watch, mould, IC, mobile phone keypad, etc. Bit map marking can carve beautiful pictures on the surfaces of metal and plastic, and the marking speed is 3-12 times of the speed of traditional first generation lamp pump marker and second generation semiconductor marker.Mainly applied to the higher marking precision such as mobile phones buttons, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.
parameter name |
parameter valus |
average output power |
10W/20W |
Laser wavelength |
1064nm |
Power adjustment range |
10-100% |
Laser repeat frequency |
20-100KHz |
Output beam quality |
<1.5M2 |
The depth of marking line |
≤1.2mm |
Minimum focusing spot |
0.005mm |
Minimum character height |
0.15mm |
repeatability precision |
±0.001mm |
Maximum marking speed |
8000mm/s |
Marking format |
Graphics, text, bar codes, two-dimensional code, date, shift, batch number, serial number, file link |
operating system |
WINXP Chinese operation interface, support PLT, PCX, DXF, BMP formats ,directly use SHX, TTF font |
Standard marking range |
100mmx100mm |
marking range |
250mm×250mm 160mm×160mm 200mm×200mm |
Computer parameter |
CPU:intel 2700M G1620 500G
internal storage 2048M Disk:250G
displayer: 18.5" liquid crystal
|
Software systerm |
WINXP (professional marking software)
|
Three dimensional table travel |
|
location indicator |
wavelength 1064NM |
|
|
barcode-type |
CODE39, EAN,CODE 128, ENA,ENA_128,DataMatrix,upc_A ,PDF417 |
Support file format |
DFX,BMP ,JPG,PNG, TIF,PCX,TAG,GIF,PLT |
Comsume power |
≤160W |
Power supply |
220V±10%/50Hz/4A |
Cooling way |
air cooling |
Control interface |
USB |
Laser module life |
>100000(H) |
Laser device |
max photonics |
field lens |
Singapore |
Operating environment |
Clean,stable |
Shanghai Dawn Real Laser Technology Co. Ltd., is located in Shanghai City, Jiading District Anting Industrial Park, is a high-tech laser equipment a set research and development, production, sales, service in one of the manufacturing enterprise. Independent R & D and production of semiconductor laser marking machine, laser marking machine, laser marking machine, laser engraving machine, laser crystal device has been widely used at home and abroad, and obtained unanimous recognition of customers. The predecessor of the company is located in the "China" in Optics Valley East Lake high tech Development Zone, its R & D center by the laser industry, senior technical staff jointly formed around Optics Valley, and various well-known university in the field of laser master student supervisor to maintain close cooperation, development of new products, test and improvement. We will always stand in the forefront of science and technology, service in the vast number of customer groups. Companies adhere to the "truth-seeking, pragmatic, integrity, innovation, " the enterprise spirit, adhering to the "service oriented, technology first, customer first" business philosophy, light solid laser with strong technical strength and brand strategy, continue to win new and old customers trust and support. Shanghai bright solid laser has a large number of experienced, high quality, highly educated workforce, the bachelor's degree or above accounted for more than the total number of employees 80%, with laser testing, professional testing equipment, light solid will be first-class talent and first-class manufacturing technology of a stream
