China High Efficiency Impact Fine Crusher with Good Performance

Product Specifications

Prod Model:	PCX1010
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Crusing
Color:	as Request
Price:	Competitive
After-Sale Serive:	for Whole Using Life
Type:	Impact Crusher
Object:	Metal
Drive:	Electric
Crushing Style:	Impact
Crushing Degree:	Intermediate Crusher
Principle:	Fixed Culling
Finished Surface:	Outer Surface Process
Tongs' Features:	Adjustable Tongs
Cutter Material:	High-Speed Steel
Compressive Strength (',For Crushing):	<350mpa

Product Description

PCX series of impact crusher are optimized after adopting advanced techniques. It's widely applied in mining, energy, transportation, construction and chemical industry and mainly used to crush many kinds of large, medium, small hard size materials with compression resistance no more than 350Mpa, in the fields of highway, reservoir, railway, airport and other fields that need rock with cubic shape. It can crush granite, basalt, bluestone, etc the diameters of which are from 100mm to 500mm, and its crushing compression strength is not more than 320Mp. They are ideal choice for crushing and screening.

Features of impact crusher
1. Special structure, connected without key, high chrome hammer, unique impact liner, deal with hard material, high efficiency and save energy, cubic shape of product, adjustable output size.
2. The impact crusher is distinguished for unique structure, keyless connection, high-chromium plating hammer and special impact liner plate;
3. It is capable of highly efficient hard rock crushing while saving energy;
4. The product is in the shape of a cube, and the discharge grain size is adjustable to simplify the crushing circuit.

Structure of impact crusher
The materials are bumping with each other when being sent to the space between the plate hammer and the impact plate. The materials become cracked, loose and then comminuted by knocking at the plate hammer. The materials with grain size smaller than the gap between impact plate and plate hammer will be discharged.

The main advantages of impact crusher
1, Simple structure, small volume, light weight, large production capacity, so the production cost is low. Big feeding port, high crushing cavity, adapt to the high hardness material;
2, Ore crushing along the joint surface, therefore, less power consumption, high efficiency;
3, Big crushing ratio, can reach 40, thus simplifying crushing process, can make the three sections of the broken into two segments or a broken, lower mill equipment costs;
4, Counterattack plate and plate hammer clearance can convenient adjustment, the effective control of the material particle size, particle shape well;
5, High chromium plate hammer, impact resistance, abrasion resistance, impact large;
6, Keyless connection, maintenance is convenient, economic and reliable;
7, Complete crushing function, high productivity, low abrasion, high comprehensive benefit;
8, It has selective crushing effect, and the broken product granularity evener, mostly were made cube shape stones. For bridge construction, construction of the high-speed road, port, airport has a wide range of applications.

Working principle of impact crusher
When the impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop untill the material are crushed to the required size and then discharged from outlet.

Specification of imapact crusher

Model and specification	Size of feeding hole (mm)	Max. feeding Size (mm)	Discharging size (mm)	Discharging Width Control (mm)	Productivity(t/h)			Power
					Cement Clinker	.Limestone	Glass sand
800×400	400×185	120	≤5	5-20	20-30	30-45	35-45	22-37
800×600	500×250	180	≤5	5-20	35-40	40-55	45-55	37-45
800×800	550×330	180	≤5	5-20	35-45	60-65	55-65	37-45
1010×1010	1000×350	180	≤5	5-20	45-55	60-75	65-75	45-55
1200×1000	1200×400	180	≤5	5-20	80-110	80-100	80-100	90-110
1200×1200	1200×450	180	≤5	5-20	100-110	90-100	90-120	110-132
1400×1400	1500×500	190	≤5	5-20	100-150	100-150	120-150	160
1600×1600	1600×550	190	≤5	5-20	170-210	190-250	190-250	250
1800×1800	1800×800	190	≤5	5-20	250-270	280-310	280-310	280
