Product Specifications
| Markets: |
North America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Size: |
3000*750*850mm |
| Accessories: |
Optional |
| Worktop: |
Optional |
| Pedestal Or Suspension: |
Type |
| Warranty: |
3 Years |
| Kind: |
Table |
| Folded: |
Unfolded |
| Usage: |
Laboratory, Hospital, School |
| Color: |
Optional |
Product Description
The side bench should be customized.
Structure: C-Frame, H-frame, O-frame, floor standing, pedestal, hexagonal style are available. 60*40*2mm rectangular square steel tube spraying epoxy resin powder coating, chemical resistant. 200KG weight bearing per square meter.
Work Top: The below options are available. All the lab worktops is chemical resistant, heat resistant, against solvent, acid and alkali resistant, scratch and impact cutting resistant. Monolithic smooth, non-glare finish.
Phenolic tops: 13/16/19/25mm thickness of Wilsonart Chemsurf chemical resistant laminate; 13/15/19/25mm thickness Belmax Lab grade phenolic resin laminate.
Epoxy Resin Tops: 13/16/19/25mm Durcon Epoxy Resin Work surface.
16/19/25mm Siruike lab grade epoxy resin tops.
Ceramic tops: 20mm/30mm Ornices Ceramic Work Top.
13mm/15/19mm Trespa tops.
13mm Compact tops.
Doors and drawers panel: Made of 18mm high pressure semi-solid wood (MDF) covered with 0.4mm High Pressure Laminate (HPL) on both sides with 3 mm PVC edging strips.
Optional Sink: International standard lab grade PP sink, epoxy sink, ceramic sink are available for option.
Reagent Rack: The main frame is made of 1.5mm thickness of cold-rolled steel plate. The adjustable shelve are made of 12mm thickness of reinforce glass with stainless steel tube for guardrail.
Electric Fitting: Sockets and power point all are optional for electric supply. According to customer specification.
Water Faucet: Cold & hot water outlet, two way water Outlet, three way water outlet are available.
Accessories: Pegboard, eyewash, gas outlet are should be used in the lab bench.
Hinge: 105/175 degree open type high quality hinge; 2.0mm thickness 304# stainless steel hinge; Ydraulic hinge are available.
Handle: 304# Stainless steel handle; Embedded aluminum handle with epoxy coating, lines handle are available.
Slideway: Stainless steel self-closing three section slide rail, no noise. Hydraulic slideway are available.
Please be noted: All the specification and requirement should be customized.
Frame |
C-frame, 50*100*1.5mm and 40*190*1.5mm square steel spraying 75μm epoxy powder coating |
Cabinet body |
1.2mm thick cold-rolled steel with 75μm epoxy powder coating |
Dimension |
L*1500*850mm (or customized) |
Worktop |
16mm thick lab black phenolic resin countertops |
Hinge |
DTC175º open type high quality hinge |
Handle |
C frame stainless steel high quality handle |
Slideway |
Self-closing three section slide rail, no noise |
Foot |
Adjustable foot |
Socket |
Special lab Multi socket. double electric, international standard |
Gas valve |
Solid brass body, high gloss epoxy powder coating |
Guangdong Huilv Laboratory Equipment Scientific & Technological Co., Ltd. is a specialized manufacturer of modern lab furniture. We integrate consultation, production, installation, and after-sales service together.
We have attained ISO9001: 2000 and ISO14001: 2004 certifications. Our company mainly produces various kinds of laboratory furniture and devices.
Our company has been established for 10 years since 1999. We furnished high-quality products and excellent service based on newest design and modern production technology.
We have regarded the quality of products as the life of our company. At the same time, we have extended our sales network to other fields such as layout before sale, consultation and design, specialized installation, and regular feedback.
We focus on establishing a modern lab of safety, high-efficiency and personality for customers.
