Product Specifications
| Prod Model: |
FS-DR-5/1.6 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| OEM&ODM: |
Welcome |
| Un: |
5V DC |
| Uc: |
6V DC |
| Color: |
Gray |
| Imax: |
10ka |
| In: |
5ka |
Product Description
SPD FS-DR-5/1.6 is for CCTV protection Un DC6V, Imax 10kA.
1. Surge protector Characteristic for FS-DR-5/1.6
- DIN rail data surge protector are applied to control signal double wire circuit in LPZ0 to LPZ3, e. G. 4~20mA circuit, RS485 circuit, RS422 circuit, gas detector, car-park system, CCTV remote monitor, remote control circuits.
- Common and difference surge protection mode, excellent performance.
- The pluggable module allows a fast replacement in case of fail.
- The grounding is realized through an earthing-clip on the DIN-Rail and / or earthing -clamp.
- No limiting in operating current due to parallel connecting method.
- Mounting on 35mm Rail, small space.
-Un 5VDC, Uc 6VDC
2. APPLICATION of surge protectorFS-DR-5/1.6:
Control signal double wire circuit in LPZ0 to LPZ3, e. G. 4~20mA circuit, RS485 circuit, RS422 circuit, gas detector, car-park system, CCTV remote monitor, remote control circuits.
3. Surge protector Certificate
CE-signal
We also can supply more of product for signal line system lightning protection
If you are interested in, please feel free contact to me!
| Model No.: FS-DR-5/1.6 |
| Rated voltage | Un | 5V DC |
| Max. cont. operating DC voltage | Uc | 6V DC |
| Nominal discharge current (8/20μs) | In | 5kA |
| Max. discharge current (8/20μs) | Imax | 10KA |
| Voltage protection level L/L | Up | <=50V |
| Voltage protection level L/PE | Up | ≤ 45V |
| Response time (L/L, L/PE) | tA | ≤ 10ns |
| Installation | 35mm DIN Rail |
| Enclosure color | Yellow or Gray |
| Test ing standard | IEC 61643-21:2000 |
Fatech Electronic (Foshan) Co., Ltd., is a professional manufacturer on R&D, production and sales of lightning and surge protection products. We have two centers (R & D center, marketing center) and joint venture manufacturing bases in China.
Our main products including:
- Surge arresters for protection of photovoltaic system,
- Surge protection devices for protection of power supply systems,
- SPD surge protectors for protection of signal system,
- Lighting rod,
- Test devices,
- Metal oxide varistors.
Wide range of lighting & surge protection products assured you a one stop shopping location for all your need and professional technical support.
We have an independent testing laboratory, and a complete set of advanced testing equipment, including impulse current generator, the SPD Test System of Thermal Stability, varistor tester, lightning device tester, & TOV testers. We built up a complete quality control system, and strict process control system, product's stability & reliability are qualified by users.
Our company gathered authority technical experts and professionals, including 2 senior engineers, 5 engineers, and 11 excellent technicians with more than five years experience in lightning and surge protection industry. FATECH is well-known registered trademark, our products have achieved certificates of CE, and the company is achieved ISO9001-2008 quality system.
Based on our superior location advantages (It needs 50 minutes drive from Guangzhou Baiyun International Airport, 2 hours drive from Hong Kong), adhering to the business philosophy - "quality first, customer first, sustainable development", we are encouraging independent innovation, brand influence is increasing day by day, the products is selling to more than 30 countries in Europe, Latin America, Asia-Pacific and other regions.
Here are the advantages of us:
1. Stable Quality --- Product performance is stable and reliable.
2. Competitive Price --- Strict cost control system achievements very competitive prices.
3. Fast and always on-time delivery --- Leading technology and production capacity advantage make sure the short & fast delivery and always on-time.
4. ODM & OEM service supplied --- We are able to make not only standard surge protection devices, but also special products according to customer's requirement...
5. Professional on R&D and manufacturing --- With the capability and experience to provide customers with lightning and surge protection applications solutions
