Cjx2-40n (LC1-D4011) New Type AC Contactor

Product Specifications

Prod Model:	SHX2N40
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Pole:	3
Type:	AC Contactors
Electricity Type:	AC
Phase:	3
Size:	/
Theory:	/
Usage:	/
Protective Characteristics:	/
Load:	/
Action Principle:	/

Product Description

LC1-D AC Contactor

Application
LC1-D series AS contactor is suitable for using in the circuits up to the rated voltage 660V AC 50Hz or 60Hz ,for making ,breaking frequently starring & controlling the AC motor Combined with the auliliary contact block,timer delay & machine interlocking device atc,it becomes the delay contactor mechanical interlocking contactor star-delta starter With the termal relay, it is combined into the electromagnetic starter.

Standards:
The Contactor is produced according to IEC947-2 VDE0660 & BS5452.

Specification

Type		CJX2-09	CJX2 -12	CJX2-18	CJX2-25	CJX2-32
Rated working	AC3	9	12	18	25	32
current(A)	AC4	3.5	5	7.7	8.5	12
AC3capacit of phase	220V/230V	2.2	3	4	5.5	7.5
123 3quirrel-cage motor	380/440V	4	5.5	7.5	11	15
AC3(kw)	415V	4	5.5	9	11	15
	440V	4	5.5	9	11	18.5
	500V	5.5	7.5	10	15	18.5
	660/690V	5.5	7.5	10	15	18.5
Rated thermal current(A)		20	20	32	40	50
Eletrical life	AC4X104	20	20	20	20	20
	AC3X104	100	100	100	100	80
Mechanical life X 104		1000	1000	1000	1000	810
Number of the contacts		3P+NO
		3P+NC

Type		CJX2-40	CJX2-50	CJX2-65	CJX2-80	CJX2-95
Rated working	AC3	40	50	65	80	95
current(A)	AC4	18.5	24	28	37	44
AC3capacit of phase	220V/230V	11	15	18.5	22	25
123 3quirrel-cage motor	380/440V	18.5	22	30	37	45
AC3(kw)	415V	22	25	37	45	55
	440V	22	30	37	45	55
	500V	22	30	37	55	55
	660/690V	30	33	37	45	55
Rated thermal current(A)		60	80	80	125	125
Eletrical life	AC3X104	80	60	60	60	60
	AC4X106	15	15	15	10	10
Mechanical life X 10o		800	800	800	600	600
Number of the contacts	3P+NC+NO

...........................................................................................
