Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tank Size: |
1500*800*800mm |
| Ultrasonic Power: |
8kw |
| Heating Power: |
16kw |
| Ultrasonic Direction: |
Three Sides or More |
| Voltage: |
380V |
| Application: |
Auto-Maintenance, Industrial Clean |
| Machine Type: |
Industrial High Pressure Cleaning Machine |
| Fuel: |
Electric |
| Clean Type: |
Industrial Ultrasonic Cleaner |
| Cleaning Process: |
Solvent Cleaning |
| Certification: |
["ISO, ISO, ISO, ISO", "ISO, ISO, ISO"] |
Product Description
Ultrasonic cleaning has been proven to be the most efficient method of removing contaminants--such as grease, oil, wax, fluxes, fingerprints, oxides and other deposits--from visible and invisible surfaces, holes and cracks. For the action of ultrasonic wave occur in the liquid, whatever the stuff will be, once it gets in touch with the liquid, it can be cleaned thoroughly. The process is especially fitted for those have complicated shape or many cracks, also for smooth or weak stuffs that cannot be cleaned by hard instrument.
After-sale service lifetime equipment maintenance regular customer visit
1. Overall equipment warranty one year;
2. Responsible for equipment debugging and training operators;
3. Provide the wire connection drawing, the operate CD;
4. Provide a set of spare parts for free;
5. Provide life-long services at preferential price.
Sinobakr is the professional manufacturer cooperated with the foreign company specializing in the production of piezoelectric ceramic, transducer parts, ultrasonic equipment, etc. Sinobakr lies in China Ultrasonic manufacture base. We have got a professional team in R&D and manufacture with the strong background and the modern management of ISO 9001, and the introducing of ultrasonic technology from the developed countries, Germany.
|
Model |
BK-1800 |
BK-2400 |
BK3600 |
BK-4800 |
BK-6000 |
BK-7200 |
BK-10000
|
BK-12000 |
|
Ultrasonic Power |
1.8KW |
2.8KW |
3.6KW |
5.2KW |
7.2KW |
8.0KW |
10.8KW |
21.6KW |
|
Heating Power |
4KW |
6KW |
9KW |
12KW |
15KW |
18KW |
20KW |
32KW |
|
Voltage |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
|
Tank Size(mm)(LxWxH) |
600*480*450 |
750*550*480 |
1000*550*560 |
1200*650*650 |
1450*720*730 |
1500*800*800 |
1700*900*800 |
2200*1200*1000 |
Product Size(mm)
(LxWxH) |
760*770*680 |
910*850*770 |
1160*850*870 |
1400*1030*980 |
1650*1190*1100 |
1700*1280*1150 |
1960*1450*1150 |
2200*1800*1350 |
|
Ultrasonic direction |
three sides |
three sides |
three sides |
three sides |
three sides |
three sides |
three sides |
three sides |
|
Dregs tank |
have |
have |
have |
have |
have |
have |
have |
have |
|
Overflow device |
have |
have |
have |
have |
have |
have |
have |
have |
