| Supplier: | Changcheng Electrical Group Zhejiang Technology Co., Ltd. |
|---|---|
| Price: | US $ 3.28-30.99/Piece |
| Min Order: | 50/Piece |
| Quantity:: | |
| Trade Terms: | FOB,CFR,EXW |
|
|
| Prod Model: | YCC1 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency: | 50 / 60Hz |
| Theory: | Electromagnetic Relay |
| Size: | Miniature |
| Usage: | Lathe Relay |
About CNC
CNC AC Contactor YCC1(LC1) 660V contactor electrical contactor
CNC AC Contactor YCC1(LC1) 660V contactor electrical contactor is suitable for using in the circuits up to the rated voltage 660V AC 50/60Hz, rated current up to 95A,for making breaking, frequently starting & controlling the AC motor. Combined with the auxiliary contact block, timer delay &machine-interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star delta starter. With the thermal relay, it is combined into the electromagnetic starter. The contactor is produ ced ac cord ing t o IEC 6094 7-4.
In most time, the buyer need not to pay any customs. Well declare it as a gift and a low value to avoid the tax.But sometimes in some countries, the customs officer is strict. We are not accountable for any customs fee, Please check it out the customs policy at your own place, such as Italy and Holland. If you have to pay thecustoms fees, it is your duty to your own country, the buyer should understand this situation. Buyers are responsible for any insurance. Please contact with us advance if you need.
China post air mail / Hong Kong post air mail /Singapore post air mail takes about 7-40 days(or more) at usual;DHL/UPS/FEDEX takes about 3-7 days at usual; EMS takes about 7-15 days at usual.
1.China Top 100 Industrial Electrical Enterprise
2.Netion High-tech Enterprise
3. Our Laboratory is China Key Industrial Electrical Laboratory;
4. We have completely sales service system, ensure every detail is going smooth.
5. We have new designed products each year by our R&D Dpartment.
6. Perfect testing system ensure each product is qualified.
7. Want know more of us? Waiting for your inquiry.
| Type | YCC1-D09 | YCC1-D12 | YCC1-D18 | YCC1-D25 | YCC1-D32 | ||
|
Rated operational current (A) |
380V | AC-3 | 9 | 12 | 18 | 25 | 32 |
| AC-4 | 3.5 | 5 | 7.7 | 8.5 | 12 | ||
| 360V | AC-3 | 6.6 | 8.9 | 12 | 18 | 21 | |
| AC-4 | 1.5 | 2 | 3.8 | 4.4 | 7.5 | ||
| Rated conventional thermal current (A) | 20 | 20 | 32 | 40 | 50 | ||
| Rated insulation voltage (V) | 690 | 690 | 690 | 690 | 690 | ||
|
Rated operational power in category AC-3kw |
220V | 2.2 | 3 | 4 | 5.5 | 7.5 | |
| 380V | 4 | 5.5 | 7.5 | 11 | 15 | ||
| 660V | 5.5 | 7.5 | 10 | 15 | 18.5 | ||
|
Intermittent periodic duty-type motor frequency AC-4kw |
380V | 1.5 | 2.2 | 3 | 4 | 5.5 | |
| 660V | 1.1 | 1.5 | 3.7 | 4 | 5.5 | ||
|
Operation cycles (times/hour) |
Electrical | AC-3 | 1200 | 1200 | 1200 | 1200 | 600 |
| AC-4 | 300 | 300 | 300 | 300 | 300 | ||
| Mechanical | 3600 | 3600 | 3600 | 3600 | 3600 | ||
| Electrical life (X 10³times) | AC-3 | 100 | 100 | 100 | 100 | 80 | |
| AC-4 | 20 | 20 | 20 | 20 | 20 | ||
| Mechanical life(X 10³times) | 1000 | 1000 | 1000 | 1000 | 800 | ||
| Matching fuse model | RT16-20 | RT16-32 | RT16-40 | RT16-50 | |||
| Screw size | M3.5 | M3.5 | M3.5 | M4 M4 | M4 M4 | ||
| Tightening torque(N@m) | 0.8 | 0.8 | 0.8 | 1.2 1.2 | 1.2 1.2 | ||
| Power of AC coil | 50Hz | Close(VA) | 70 | 70 | 70 | 110 | 110 |
| Remain(VA) | 9 | 9 | 9.5 | 14 | 14.0 | ||
| Power(W) | 1.8-2.7 | 1.8-2.7 | 3-4 | 3-4 | 3-4 | ||
| Power of DC coil | Power(W) | 9 | 9 | 11 | 11 | 11 | |
| Operation range | Voltage of closing: 85%Us-110%Us; Voltage of releasing: 20%Us-75%Us, DC:10%Us-75%Usl | ||||||
| Specification of auxiliary contacts | AC-15: 360VA DC-13: 33W Ith: 10A | ||||||
