CNC Deep Hole Skiving Roller Burnishing Machine
(TGK25)
TGK25 Series deep hole skiving roller burnishing machine is an ideal equipment that make the hydraulic oil cylinder, deep hole processing and high-precision boring and rolling. Compared with the ordinary deep hole machine, the production efficiency can improve 5-10times. Higher efficiency and accuracy are the main advantages of this product, comply with the demands of the rapid development of modern society.
TGK25 Series deep hole skiving roller burnishing machine mainly aimed at the steel pipe boring and rolling processing, the efficiency can reach 1m in 2-3 minutes. The machine itself has a strong rigidity and accuracy stable good, main axis rotated range widely, feeding system driving by AC-servo motor, can meet the needs of all kinds of deep processing technology. Oil cooler grant fastening and workpiece pull-up adopts hydraulic device, instrument display, safe and reliable. It is mainly used to
Drilling and boring drilling and can also be used to rolling processing. When boring holes, it adopts front row chips technology.
Specifications
Boring diameter range
40-250mm
Boring depth range
500-5000mm
Bed width of machine
650mm
Spindle center height
350mm
Spindle rotary range
3~1100r/min(no class)
Headstock spindle hole
75mm
Front spindle cone
85mm
Feeding speed range
5-2000mm/min(no class)
Pallet rapid moving speed
6000mm/min
Main motor power
45kW, AC servo spindle motor
Feed motor power
36 N M, AC servo motor
CNC system
DELTA of Taiwan H4CP-T
Hydraulic pump motor power
1.5KW, 1440r/min
Cooling system motor power
5.5KW, 1group 7.5KW, 2groups
Cooling system rated pressure
2.5Mpa
Cooling system flow
100L/min, 200L/min, 200L/min
Hydraulic system rated work
6.3Mpa
Note: Payment terms and Delivery time
1. Payment: T/T payment.
2. Advanced payment: After sign the order, first pay 30%, then we start to manufacture.
3. Delivery payment: Before delivery please paid 70%.
4. Delivery time: 60-90 days, after sign the order.
5. Package: Wooden box.
6. Minimum Order Quantity: 1 set or 1 piece.
Dezhou Boao Machinery Co., Ltd. is committed to deep-hole machinery development and manufacture. Deep-hole boring diameter is from 1.5mm to 1250mm; Size and types is complete. The longest is 15m. The main products include Deep-hole drilling&boring machine(tb2120)\deep-hole boring machine(tb2225\tb2235\tb2250)\drill collar plane(tz2120)\CNC deep-hole powerful honing machine(2mk2125\2mk2135\2mk2150)\CNC deep-hole drilling machine(zk2120\zkb2120\zk2130)\CNC deep-hole drilling&boring machine(tk2120\tk2125)\CNC deep-hole boring machine(tk2235\tk2250)\huge and middle size CNC machine(ck61125D\ck61140L\ck61160L)\large tube cylindrical grinder.
With our excellent and cheaper products, good after sale-service and specialized management to make friends with all over the world, sincerely hope to establish long-range and table trade relationship with you as well as common advancement together.
