Product Specifications
| Prod Model: |
DZL coal fired boiler |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Coal Fired Steam Boiler: |
Coal Fired Boiler |
| Place Style: |
Vertical |
| Gas Flow Type: |
Water Tube |
| Usage: |
Industrial |
| Pressure: |
Low Pressure |
| Burning Style: |
Chamber Combustion Boiler |
| Water Circulation: |
Natural Circulation |
| Manufacturing Level: |
B |
| Media: |
Electric Heating Pipes Electric Heating Pipes |
Product Description
Features:
1, Boiler is single drum-type quick assembly three pass fire and water tube boiler, with large heating surface and high thermal efficiency;
2, Boiler has advantages of compact structure, the reasonable water cycle design, and quick start;
3, The advanced chain grates assure reliable operating, less coal missing and energy-saving Also reduce installation and maintenance workload of the grate;
4, Grate with reasonable combustion air distributor makes fuel burning fully and improves machine efficiency;
5, Using a long arch, increasing the effective area of grate, good coal adaptability and fuel burning fully;
6, High quality steam, steam drying degree of 96% or more;
7, The boilers have the pressure, temperature, water and other multi-chain security control;
8, Automatic control system, a high degree of mechanization, simple and convenient operating;
9, Boiler manufacturing is strictly according with the relevant national standards of manufacture;
10, The boiler is saled in integrated form from factory that makes the installation period short. The boiler is very popular for our customer by it's compact structure, beautiful appearance, bright color and luster.
|
Name |
Rated Vaporation |
Operating Pressure |
Saturation Steam Temp. |
Inlet Water Temp. |
Heating Surface Area |
Grate Area |
Design Thermal Efficiency |
Outline Dimension |
Total Weight of Boiler |
Design Coal Types |
|
Unit |
t/h |
Mpa |
centigrade |
centrade |
m2 |
m2 |
% |
mm |
Kg |
II, III Bituminous Coal |
|
DZL0.5-0.7-AII |
0.5 |
0.7 |
170 |
20 |
21.3 |
1.1 |
≥ 72 |
4500*2000*2900 |
9500 |
|
DZL1-0.8-AII |
1 |
0.8 |
176 |
20 |
32 |
2 |
≥ 74 |
5000*2200*3000 |
14500 |
|
DZL1-1.25-AII |
1 |
1.25 |
194 |
20 |
32 |
2 |
≥ 74 |
5000*2200*3000 |
15300 |
|
DZL2-0.7-AII |
2 |
0.7 |
170 |
20 |
74 |
3 |
≥ 76 |
5400*2535*3380 |
19000 |
|
DZL2-1.0-AII |
2 |
1 |
183 |
20 |
74 |
3 |
≥ 76 |
5400*2535*3380 |
19800 |
|
DZL2-1.25-AII |
2 |
1.25 |
194 |
20 |
74 |
3 |
≥ 76 |
5400*2535*3380 |
20500 |
|
DZL4-1.25-AII |
4 |
1.25 |
194 |
20 |
121 |
5.47 |
≥ 78 |
6800*2500*3500 |
18500 |
|
DZL4-1.6-AII |
4 |
1.6 |
204 |
20 |
121 |
5.47 |
≥ 76 |
6800*2500*3500 |
19800 |
|
DZL6-1.25-AII |
6 |
1.25 |
194 |
20 |
136.9 |
5.47 |
≥ 78 |
8360*3000*3520 |
33000 |
