Product Specifications
| Prod Model: |
HN-235T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Hn-235t |
| Voltage: |
DC7.2V(Lithium Battery 7.2V/1400mA) |
| Current: |
900mA |
| Output Power: |
26dBm Adjustable, Stepping 1dBm |
| Bandwidth: |
2/2.5/4/8MHz |
| Decryption: |
AES |
| Transmission Delay: |
<500ms |
| Fec: |
1/2, 2/3, 3/4, 7/8 |
| Guard Interval: |
1/32, 1/16, 1/8, 1/4 Adjustbale |
| RF Port: |
SMA |
| Application: |
Image Transmission |
Product Description
HN-235T Secretly filmed SDI COFDM wireless video transmisson, highly integrated mobile NLOS ((Non Line of Sight) device, integrated design with antenna, COFDM digital modulation, MPEG-2 audio and video digital compression, small portable component. It can transfer high quality video and audio singal in a sheltered environment and high-speed mobile environment. It can be used in hidden investigation, image surveillance, realtime wireless video transmission and etc.
Feature
Using COFDM modulation technology and MPEG-2 image compression technology
Support NLOS, transmit in high-speed movement
DVD grade HD images and sound
Highly integrated modular design
High-performance\High- capacity lithium battery (replaceable)
Small size\Lightweight\Easy to carry\Using air-cooling fin aluminum shell
Product application
The product is widely used in covert investigation, video sureilllance, wireless image transmission.
| Model | HN-235T |
| Voltage | DC7.2V (lithium battery 7.2V/1400mA) |
| Current | 900mA |
| Video input | AV:3.5mm port,external SD analog video signals |
| Camera:2.5mm port ,external HN-420 HD camera |
| Radio Frequency | The optional 300-900MHz,stepping 1MHz ( It can be customized for other frequencies) |
| Output power | 26dBm adjustable, stepping 1dBm |
| Bandwidth | 2/2.5/4/8MHz |
| Modulation | COFDM |
| Decryption | AES |
| Transmission delay | <500ms |
| FEC | 1/2,2/3,3/4,7/8 |
| Guard Interval | 1/32\1/16\1/8\1/4 adjustable |
| Parameter adjustment | Through the digital control panel to set the relevant parameters |
| Video processing method | MPEG-2 |
| RF port | SMA |
| Dimensions | 100mm*59mm*22mm |
