| Supplier: | Riotouch Technology |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 10/Piece |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | P series |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Technology: | Infrared Technology |
| Frame: | Plastic Frame |
| Color: | Blue, Orange, Grey, Green |
| Touch Points: | 2 Points - 10 Points |
| Teaching Software: | Provide |
| Size: | 55'' Till 158'' |
| Certificate: | CE, FCC, RoHS |
| Type: | Whiteboard |
| Laser Model: | Red Laser |
| P82 IWB SPECIFICATION | |
| General | |
| Model | P82 |
| Ratio | 4:3 |
| Touch Technology | Infrared Touch |
| Interface | USB2.0 or USB3.0 |
| External size | 1722×1241×38mm |
| Active area (mm) | 1606.5×1126.5mm |
| Package size | 182*9*134cm |
| Net weight | 16.5kg |
| Gross weight | 26.5kg |
| Performance | |
| Resolution(Interpolation) | 4096*4096 |
| Linearity Error | 1.5mm |
| Responsible time | 8ms |
| Response Speed | <20ms |
| Input Method | Finger, teaching point, or opaque objects |
| Touch Times | Unlimited |
| Touch Activation Force | No minimum touch activation force is required with IR touch technology |
| Minimum Touch Object | 5mm |
| Environmental | |
| Temperature | Operating: -20°C ~ 70°C |
| Storage: -40°C ~ 85°C | |
| Relative Humidity | Operating: 90%(noncondensing at max 40°C) |
| Storage: 90%(noncondensing at max 40°C) | |
| Altitude | Up to 7,000m |
| Life Time | At least 7-year |
| Electrical | |
| Operation Voltage | Typical +DC 5V, +4.75V to +5.25V |
| Power Supply | USB, power ripple max.200mV rms |
| Power | <2W, operating current<200mA |
| Agency Approvals | CE, FCC Class B,RoHS |
| Accessories | |
| Wall mount brackets | 8 |
| Installation guide | 1 |
| Extension USB cable | 5m for standard |
| IWB Pen without ink | 3 |
| CD with the software | 1 |
| Teaching point | Optional |
| Mobile stand | Optional |
| Notes: | |
| 1. All the dimensions, quantities and weight are approximate. | |
| 2. Design and specification are subject to change without notice. | |
| 3. All other brand or product names are the property of their respective holders. | |
