Applicable materials:
Wood, EPS and non-metallic materials.
Mold industries: Sculpture various large non-metallic mold can be particularly suitable for any kind of Foam (EPS) mould, wooden ship model, wooden model aviation and other wooden mould. 2. Foam industry: Can carve and cut on any kind of Foam (EPS), do 2D and 3D dimension processing.
3. Three dimension: With 4 axises, Big diameter Rotary, can do any kind of 3D cylinder material and mould processing for advertisment industry, cloth and shoes industry
Processing effect:
It can manufacture the following effects: Engraving, cutting, milling, drilling, relief, shadow, enchasement and so on.
Features:
1. We use the world best brand for the machine's main parts, such as Original Italy Imported HSD Spindles, Taiwan HIWIN Big Size Straight Guide Rail, Japan Yaskawa Servo Motor and Driver system, Taiwan SYNTEC Control System, Germany Ball Screw, France Small Electronic parts, Taiwan DELTA Inverter, Taiwan Planetary Gearbox, etc...All of these can make sure the machine's working perfectly, High speed and efficiency.
2. (1)Balance cylinder, not only it can work more stable, but also can protect the Germany Ball Screw and Servo Motor.
(2) Planetary Gearbox for X and Y axis, which will keep the machine's perfect traveling and working.
(3)All of X, Y and Z axises will have Dust cover to prevent any dust to dirt or effect every axis's working and traveling, and also will keep the machine's longer life time.
3. Heavy Hard Steel Lath Body, keep the machine's working High stability. Whole machine is welded with seamless steel structure, dealing with Time-treatment, the stability is excellent, never to be deformed.
4. Three axis XYZ Effective Traveling size is: 2000mm*3000mm*1100mm
Effective plane table working area is: 2000mm*3000mm*1000mm;
Rotary Diameter: Can work on the material within 800mm diameter,
5. The machine adopts gantry movement, it can process any kinds of materials freely.
6. Well compatibility: CAD/DAM designing software e. G. Type 3/Artcam/Castmate/Wentai etc.
7. Has the function of recarving after break point and power failure.
8. Has the function of forecasting process time. Taiwan Imported Syntec control system can completely work off-line and do not take any computer resources.
9. Perfect oil-inject system makes maintenance much easier.
10. Tools' Specification: You can choose different diameter and length tool according to your processing.
MORE ROUTERS INFO:
We have three types woodworking CNC Router:
(1)One is general Standard Level Model, such as CC-M1325, CC-M1530, CC-M2030, etc...
They are mainly used for any kinds of wood's general Cutting and Engraving.
(2)The second kind is Middle Level Model, also called simple auto-tool changer machine,
Mainly used for furnitures and doors making, such as cutting, engraving, driiling lock holes and milling.
(3)The third kind is High Level Models, just Auto-tool Changer CNC Machine Center,
Most parts are International Best Brand, also mainly used for any kind of woodoworking requirements
For material just stone and metal, we have professional stone engraving router, and Plasma machine.
OUR SERVICE:
Wanrranty: 12 moth
Free software, necessary tools and accessories
Free training in our factory(first 5 days free overseas)
Engineers oversea available
CE, ISO CIQ, C. I. Provided as your need.
Contact me which model you interested, Quotations with picture will send you sooner.
Mobile: 0086-13583195229, lets talk the details!
Jinan Gaoye Import and Export Trade Co., Ltd. is an industry and trade combined company. Factory name is Shandong Chencan Machinery Co., Ltd.
Shandong Chencan Machinery Co., Ltd. is a High-tech enterprise ingrating product and production. Located in Qihe Economic Development Zone, Shangdong Province, with floor space of 20000square meters and 13000square meters of modern workshops, 160 employees and total assets nearly 60 million yuan.
