Performance & Feature:
1. The latest improved gear case with a 360°non-stopping register set
2. Pneumatic scraping blade device horizontally moving back and forth
3. Closed oven and automatic constant temperature system
4. Double-oven drying system
5. Magnetic powder controller applied to unwinding traction with automatic tension control
6. Magnetic powder clutch for winding traction and winding process
7. Turn double-station winding and unwinding mechanism for receiving and replacing materials with no stop
8. Inflatable air shaft for unwinding/rewinding material loading
9. Printing linear speed and meter counting display
10. Pneumatic pressing and traction system
11. Traction roller controlled by air pressure
12. The main motor adopting frequency converting control
Purpose
This machine is suitable for printing various soft packing materials of excellent printing performance including roll-like film, nonwoven cloth, PVC, thin leather, paper, aluminum foil and cloth and it is a ideal printing equipment for wine box, shoe bag and vest bag.
Main Technical Parameters
Model | CHCY -6/600B | CHCY -6/800B | CHCY -6/1000B |
| Printing width | 600mm | 800mm | 1000mm |
| Max. width of material | 620mm | 820mm | 1020mm |
| Max. printing speed | 80m/min | 80m/min | 80m/min |
| Max. machine speed | 100 m/min | 100 m/min | 100 m/min |
Max. diameters of
winding and unwinding | 600mm | 600mm | 600mm |
| Roll diameter | 76mm | 76mm | 76mm |
| Printing roll diameter | Φ70~Φ270mm | Φ70~Φ270mm | Φ70~Φ270mm |
| Registering precision | ±0.2mm | ±0.2mm | ±0.2mm |
| Tension control range | 3~25kg/Full Width | 3~25kg/Full Width | 3~25kg/Full Width |
| Oven heating power | 28.8kw | 36Kw | 43.2Kw |
| Total power | 38.6Kw | 47.5Kw | 56.6Kw |
| Machine weight | 8500kg | 9500kg | 10500kg |
| Overall dimension | L9300×W2300×H2300mm | L9300×W2500×H2300mm | L9300×W2700×H2300mm |
Service:
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.One year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
