Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wavelength: |
520nm |
| Beam Type: |
DOT |
| Delivery Time: |
Two Weeks |
| Housing Material: |
Brass |
| Work Voltage: |
3V |
| Work Current: |
180mA |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Type: |
P-type Semiconductor |
| Material: |
Alunimium Anodized or Brass |
| Package: |
Customized |
Product Description
Specifications
-direct green laser
-FDA ISO2000: 2008
-SGS TUV assessed supplier
-wide work temperature
-high reliability
Compact Size Mini Green 520nm Laser Diode Module (4*9mm)
Direct Diode Green Laser, Not DPSS! !
Less Power Consumption, Higher reliability and Stability, Better Effectivity! !
Compact Mini Size, More Applications! ! ! For small Gadgets! ! ! Revolution Product
Features
Wavelength: 520 nm
High brightness, optical output power: <5.0 mW
Low operating current: <180mA
Low operating voltage: 3VDC
Class IIIa laser, CDRH/RoHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: -10 to 50° C
|
Parameter |
Specifications. |
Test Conditions |
|
Wavelength |
520 nm |
Tc = 25° C |
|
Output Power |
4 ± 0.8mw |
Tc = 25° C |
|
Laser Modes |
CW |
|
|
Transverse mode |
TEM00 |
|
|
Output Aperture |
< 1.5 mm |
Factory fixed |
|
Beam Size |
< 8 mm |
Factory fixed @ 10m |
|
Divergence |
< 0.8 mrad |
Tc = 25 ± 3° C |
|
Stability |
> 80 % |
|
|
Operating Current |
< 180 mA |
Tc = 25 ± 3° C |
|
Operating Voltage |
3 VDC |
|
|
Operating Temp. |
0° C ~ 45° C |
|
|
Storage Temp. |
-20° C ~ 70° C |
|
|
Optics |
Glass Lens |
|
|
CDRH Class |
Class IIIa |
|
|
MTTF |
8000 Hrs. |
Tc = 25 ± 3° C |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
